50ml 10:1 Ratio Dual Cartridge B-System ...

High density dual component dispense cartridges for two part adhesives, epoxies, silicones and other fluids. All sets are supplied with matching pistons and a tip cap ready for filling and dispensing. Use with our range of manual and pneumatic cartridges guns. Industrial grade and silicone free.

116423 50ml 10:1 ratio dual cartridge sulzer adhesive dispensing

Dual system 50ml size 10:1 mix ratio by volume. Materials are stored in the two chambers of the cartridge system and dispensed simultaneously to the static mixer where dynamic mixing takes place. Use with 2-part epoxies, resins, sealants, silcones & polyurethanes.

This cartridge is manufactured in Polypro. The kits come with the following parts:

- 50 x Cartridge 10:1 with capacity of 50ml max.
- 50 x Vented large pistons with cap seal.
- 50 x Vented small pistons with cap seal.
- 50 x Dust tip cap
.

One of the main benefits of the system is that not all of the contents of the cartridge have to be mixed at once. When use has stopped, nozzle is removed for disposal with the cartridge closed and stored for later use, without the material curing.

Standard air-bleed pistons are shipped with this cartridge system. These dual cartridge products are compatible with either manual or pneumatic dual cartridge guns.

All products shipped are in sealed boxes or packs that include label with batch codes.


Adhesive Dispensing Ltd provide a wide range of equipment options for dispensing almost all assembly fluids - from watery liquids, solvents, primers and activators through to thick pastes, sealants, silicones, gels and epoxies.

B-System Dual Cartridge 50ml

GBP   each ex. Vat.
Excludes carriage.
Lead Time:
Ships 24 to 72 Hours

Summary: White polypro plastic body. Air bleed wiper pistons. Supplied with pistons and a nozzle tip cap. Nozzle attachment is bayonet twist-on. Use (MBHQ) or (MBHX) series mixer nozzles below with these cartridges.

Code Ratio Price GBP Add
116423 10:1   pack 50

Specifications

Material: Polypropyelene Barrel
Body Colour: White
Nozzle Attachment: Grey Cap Twist-On
Mix Ratio: 10:1 By Volume
Maximum Pressure: 100 PSI
Length: 104mm (not including tip cap)

Flow Pattern: Straight
Description: Dual Cartridge
Features: Silicone-Free/ Industrial Grade

Pack Sizes: 50


Delivery: Products shipped by courier on a tracked and insured service for stock items. Products on a longer lead time or built to order will be sent as soon as available. Customers are informed of ship dates.

Typical Applications:- Deposits of two-part resins, epoxies, polyurethanes, silicones, adhesives and other mixed assembly fluids.


MBQX05-16L Mix Nozzle 5.3mm Adhesive Dispensing Sulzer Mixpac

B-System Dispense Guns Sulzer Mixpack Manual 50ml Dual Guns Adhesive Dispensing

Excludes carriage.
Lead Time:
Ships 24 Hours

Summary: Dispense guns for 50ml dual cartridges in different mix ratios. Manual gun  (ABM-25M10) or pneumatic rod-driven gun (EDS408M).

Code Ratio Price GBP Add
ABM-25M10 10:1    each
EDS408M 10:1    each

More Info Part No. Dia. Colours Elements Length

Pack

Price GBP Add
Static Mixer Nozzle Adhesive Dispensing MBHX03-16S
Mix Nozzle Round
4:1/ 10:1 Ratio
3.2mm Natural/ Orange/ Grey 16 77.0mm 100    pack
Static Mixer Nozzle Adhesive Dispensing MBHX04-16D
Mix Nozzle Round
4:1/ 10:1 Ratio
4.2mm Natural/ Orange/ Grey 16 86.2mm 100    pack
Static Mixer Nozzle Adhesive Dispensing MBHX04-16S
Mix Nozzle Round
4:1/ 10:1 Ratio
4.2mm Natural/ Orange/ Grey 16 96.0mm 100    pack
Static Mixer Nozzle Adhesive Dispensing MBHX05-12D
Mix Nozzle Round
4:1/ 10:1 Ratio
5.4mm Natural/ Orange/ Grey 12 83.0mm 100    pack
Static Mixer Nozzle Adhesive Dispensing MBHX05-16T
Mix Nozzle Round
4:1/ 10:1 Ratio
5.4mm Natural/ Orange/ Grey 16 111.0mm 100    pack
Static Mixer Nozzle Adhesive Dispensing MBQX05-16L
Mix Nozzle Square
4:1/ 10:1 Ratio
5.3mm Natural/ Orange/ Grey 16 90.7mm 100    pack
Static Mixer Nozzle Adhesive Dispensing MBQX05-24L
Mix Nozzle Square
4:1/ 10:1 Ratio
5.3mm Natural/ Orange/ Grey 24 122.0mm 100    pack
Static Mixer Nozzle Adhesive Dispensing MBHX05-20T
Mix Nozzle Round
4:1/ 10:1 Ratio
5.4mm Natural/ Orange/ Grey 20 132.8mm 100    pack
Static Mixer Nozzle Adhesive Dispensing MBHX06-16D
Mix Nozzle Round
4:1/ 10:1 Ratio
6.5mm Natural/ Orange/ Grey 16 120.5mm 100    pack
Static Mixer Nozzle Adhesive Dispensing MBHX06-16T
Mix Nozzle Round
4:1/ 10:1 Ratio
6.5mm Natural/ Orange/ Grey 16 131.0mm 100    pack
Static Mixer Nozzle Adhesive Dispensing MBHX06-20T
Mix Nozzle Round
4:1/ 10:1 Ratio
6.5mm Natural/ Orange/ Grey 20 157.0mm 100    pack
