1oz (30ml) Pneumatic Cartridge Mini Gun Dispenser

Pneumatic cartridge gun dispensers are designed for the quite application of pastes, gels, adhesives and fluids. The 120 mini gun is the standard of the aerospace and electronics industries. Suitable for use with 1oz cartridges or Semkit cartridge mixer packages.



Semco 120 mini gun 232280

A pneumatic mini cartridge gun with quick attach bayonet retainer and quick air exhaust to reduce pressure.  For 1oz (20cc) size Semco HDPE cartridges.  This gun is used for making controlled beads or  shots of adhesives, solder pastes, slicone sealants, RTV, grease, gels, long cure or single part epoxies, mastics and potting compounds.

Load in a 1oz (30ml) size Semco plastic cartridge. Replace the retainer and screw end knob tightly to secure the cartridge. Attach a threaded nozzle or use a male luer lock adapter with any standard needle tips if more precision is required.  Press the lever for flow and adjust your regulated air supply for fine control.

Needle tip adapters can also be used with the cartridges for attachment of all standard needle tips. All guns are all covered by a 12 month manufacturers warranty.


Applications

Make beads of adhesives Beading
Potting of components Potting
Bonding of components Bonding
Sealing of components Sealing
Dispense lubricants and greases Lubricating

Adhesive Dispensing Ltd provide a wide range of equipment options for dispensing almost all assembly fluids - from watery liquids, solvents, primers and activators through to thick pastes, sealants, silicones, gels and epoxies.

Product Details

Part ID: 232280

Construction: Stainless Steel/ Aluminium/ Nylon
Colour: Black
Attachment: Bayonet retainer to handle
Weight: 250 g
Warranty: 1 Year

Size

Part Code

Lead Time

Price GBP Add
1oz 232280 Usually ships in 3-4 Weeks   each


Product Pages

    High pressure use to 100 psi
  Air exhaust reduces pressure build-up
  Quick-attach retainer and lever control
  Lightweight yet robust construction
  Quick cartridge attachment & removal
  High value dispensing solution


6oz HDPE cartridge reservoir
Cartridges


Plungers

Nozzles

Caps


Air-Powered Dispensers * Industrial Dispensing Components * Precision Dispense Valve Systems * Bench Robots

Adhesives * Packaged Components * Techkits * RatioPacks * Hingepacks * Syringe Barrels * Cartridges * Nozzles


  COMPANY INFORMATION SUPPORT CUSTOMER SERVICE
  About Us Solutions Carriage
  Shipping & Returns FAQ's Terms & Conditions
  Privacy Site Map Help
  Contact Us Assist Accounts



Prices are in Sterling GBP and exclude VAT which is charged on UK orders at checkout. Orders are encrypted on a 128 bit secure server for total security. All personal information and payment details is encrypted on SSL secure website pages. Statements, technical information and recommendations contained herein are based on tests we believe to be reliable but they are not to be construed in any manner as warrantees expressed or implied. The user shall determine the suitability of the product for his intended use and the user assumes all risk and liability whatsoever in connection therewith.

Copyright 2017 Adhesive Dispensing Ltd. All rights reserved.


  Literature
  Cartridges Brochure
  Nozzles Brochure
  Dispense Tips Brochure
  Full Catalogue
  Part Numbers List

  Information
  Important Safety Information

  Contact Us
  Equipment Recommendations
  Request a Quote
  Technical Support
  Applicator Assist

  Shipment of this product


Products are shipped globally from our UK warehouses using a courier tracked & insured courier service. We use all the main carriers. High value items are insured. We provide a POD and tracking code for customer orders.



  Maintenance of this product


Guns are robust and handle most liquids and pastes dispensed from them. The handle uses a low cost rubber gasket seal for the retainer that can be replaced after very long periods of use. Keep the trigger assembly clean and grease as required.



  Typical Applications


Guns are portable and can be used in a factory production or maintenance area, in an assembly department as well as for repair and re-work. Guns are commonly used in repair and maintenance of parts that are not so easy to reach such as aircraft maintenance. Common applications include:-


Deposits of solder paste or flux
Grease to bearings
Potting components with epoxy
RTV to seal seams
Silicone shots to bond products
Gasket sealant repair
Aircraft maintenance work
General adhesive application
