Home > Syringes > Pistons > 403LL-1B




3cc Size Syringe Barrel ...

400 series syringe barrels are cost effective components available in sizes from 1cc to 60cc. Use with air powered dispensers or these barrels work with the pistons and rods to provide a full manual syringe assembly. Our manual syringes are also available pre-assembled in sealed packs.


403LL-1B Syringe barrel 3cc black adhesive dispensing


Industrial grade 3cc/ 3ml size syringe barrels. Black (opaque) for use with all adhesives including UV cure. High density polypropylene safe for use up to 100 psi.  Precision flanges for safe attachment to 400 series receiver assembly.  Luer lock for twist on attachment of needle tips.

Use with 400 series wiper pistons. These syringes are industry compliant low friction high density polypropylene. Supplied in a sealed pack of 50 syringe barrels.  These items ship from our UK warehouse direct from stock.

All products shipped are in sealed boxes and include label with batch codes.


Adhesive Dispensing Ltd provide a wide range of equipment options for dispensing almost all assembly fluids - from watery liquids, solvents, primers and activators through to thick pastes, sealants, silicones, gels and epoxies.

Specifications:

Materials: Polypropylene
Colour: Black (Opaque)
Length: 74.67 mm - 2.94 Inch
Inner Diameter: 8.89 mm - 0.35 Inch
Outer Diameter
: 10.92 mm - 0.43 Inch
Maximum Pressure: 100 PSI (6.89 Bar)

Flow Pattern: Straight
Description: Syringe Barrel
Features: Silicone-Free, Industrial Grade
Pack Sizes: 50, 500 or 1000


Delivery: Products shipped by courier on a tracked and insured service for stock items. Products on a longer lead time or built to order will be sent as soon as available. Customers are informed of ship dates.

Typical Applications:- 400 series syringe pistons are designed for manually with an adapter and plunger rod. They are thick walled with wide flanges and so designed for high pressures. Use these pistons with pastes, adhesives, solvents, epoxies, RTVs, silicones, PVA, inks and gels.

3cc Syringe Barrels Luer Lock
Pack

Part Code

Description Lead Time

Price

Add

50 403LL-1B 3cc Syringe Barrel Black Ships in 24 Hours GBP   pack
50 403LL-1 3cc Syringe Barrel Clear Ships in 24 Hours GBP   pack

3cc Syringe Barrel Non-Lubricated Rubber Pistons
Pack

Part Code

Description Lead Time

Price

Add

50 403L-2 3cc Piston Non Lubricated Ships in 24 Hours GBP   pack
500 403L-2-500 3cc Piston Non Lubricated Ships in 24 Hours GBP   pack
1000 403L-2-1000 3cc Piston Non Lubricated. Ships in 72 Hours GBP   pack

   3cc Syringe Barrel Lubricated Rubber Pistons
Pack

Part Code

Description Lead Time

Price

Add

50 403L-2-LUB 3cc Piston Lubricated Ships in 24 Hours GBP   pack
500 403L-2-LUB-500 3cc Piston Lubricated Ships in 24 Hours GBP   pack
1000 403L-2-LUB-1000 3cc Piston Lubricated. Ships in 72 Hours GBP   pack

3cc Syringe Barrel Adapter Assemblies
Pack

Part Code

Description Lead Time

Price

Add

1 900-350-3 3cc Adapter 3 ft. Hose Ships in 24 Hours GBP   each
1 900-350-6 3cc Adapter 6 ft. Hose Ships in 24 Hours GBP   each
1 900-350-R 3cc Adapter Head Only Ships in 24 Hours GBP   each

3cc Syringe Barrel Plunger Rods
Pack

Part Code

Description Lead Time

Price

Add

50 403L-4 3cc White Plunger Rod Ships in 24 Hours GBP   pack
500 403L-4-500 3cc White Plunger Rod Ships in 24 Hours GBP   pack
1000 403L-4-1000 3cc White Plunger Rod Ships in 72 Hours GBP   pack

3cc Syringe Barrel Assemblies
Pack

Part Code

Description Lead Time

Price

Add

50 MS403LL-1B 3cc Syringe Assembly Black Ships in 24 Hours GBP   pack
50 MS403LL-1 3cc Syringe Assembly Clear Ships in 24 Hours GBP   pack
