10cc Size Plastic Syringe Barrel Piston

Adhesive Dispensing Wiper Piston Syringe Barrel

Precision components provide safe and leak free fluid dispensing from syringe barrels. These pistons wipe the inner walls of the syringe barrel to eliminate waste and fluid mess. Use with 10cc size barrels on either a pneumatic dispenser or manual syringe gun.


Pistons ensure that the pressure is evenly spread across the fluid surface to provide consistent dispensing. Wiper seal pistons prevent dripping and eliminate material waste by wiping the syringe barrel wall clean as fluid is dispensed. Maximum operating pressure is 100psi (6.9 bar).

These wiper pistons are a tighter fit for use with low to medium viscosity fluids or with mechanical devices such as our manual syringe gun to help slow down leakage past the double wiping edges.

Black rubber syringe barrel piston adhesive dispensing



This piston is pushed into the syringe barrel once fluid is inserted. Push on one side of the piston to allow air to escape as the piston is inserted down. Pre-insert the piston into an empty syringe barrel when using our filling stations.

Adhesive Dispensing Ltd provide a wide range of equipment options for dispensing almost all assembly fluids - from watery liquids, solvents, primers and activators through to thick pastes, sealants, silicones, gels and epoxies.


Suitable for...
Make dots of adhesives Adhesives
Make beads of adhesives Silicones
Potting of components Epoxies
Bonding of components Primers
Sealing of components Solvents
Dispense lubricants and greases Lubricants
Gaskets
SMT Adhesives
Material

For Barrel Size

Height

Outer Diameter

Colour


Polyethylene

10cc (10ml)

12.00mm

15.71mm White


  Product Pages

Copyright  2008 Adhesive Dispensing Ltd. All rights reserved.

    Silicone and chloride free plastics
  Compatible with 10cc syringe barrels
  Resistant to aggressive fluids & solvents
  Available direct from stock always
  Provides wiper action in syringe
  Use with all fluids from liquid to paste

Pack

Part Code

Stock

Price

Add

50 7100009WPK   GBP   pack

500 7100009W-500   GBP   pack

1000 7100009W-1000   GBP   pack




Barrels


End Caps

Adapters
Copyright  2008 Adhesive Dispensing Ltd. All rights reserved.
Tip Caps

Dispensing tips
Tips
Syringe barrels
Barrels
Cartridge reservoirs
Cartridges
Adhesive dispensers
Dispensers


Air-Powered Dispensers * Industrial Dispensing Components * Precision Valve Systems * Bench Robots

Adhesives * Packaged Components * Techkits * RatioPacks * Hingepacks * Syringe Barrels * Cartridges * Nozzles



  COMPANY INFORMATION SUPPORT CUSTOMER SERVICE
  About Us Solutions Carriage
  Shipping & Returns FAQ's Terms & Conditions
  Privacy Site Map Help
  Contact Us Assist Accounts



Prices are in UK pounds.  Vat is not charged on orders placed outside the EU and any EU orders are exempt from VAT only if a valid company VAT number is provided to us at time of order or before shipping.  Products are covered by a 12-month warranty against faults and malfunction All orders online are encrypted for safety and security.  Please read our privacy agreement for details.  We also process phone or fax payments by credit and debit card.  Please contact our accounts department if you would like to open a credit account with us.

Our new web shop is available to order these products in a number of different currencies. Please visit www.adhesivedispensing.co.uk for more details.

Disclaimer: While reasonable efforts have been made to ensure all information on this website is accurate, Adhesive Dispensing Ltd. do not assume responsibility for any errors or omissions. All specifications, illustrations, data and prices are subject to change without notice.

Copyright 2005 - 2017 Adhesive Dispensing Ltd. All rights reserved.



  Support

  Literature
  Syringe Barrels Brochure
  Dispense Tips Brochure
  Cartridges Brochure
  Nozzles Brochure
  Full Catalogue

  Information
  Important Safety Information

  Contact Us
  Equipment Recommendations
  Request a Quote
  Technical Support
  Applicator Assist

  Shipment ...


Items are shipped in the UK by a courier on a next day tracked and insured service for all items that are available from stock. Items on a lead time will be shipped as soon as they are available.



  Pistons ...


Pistons are made of plastic and have dual blades to wipe the adhesive, paste or liquid from inside the syringe barrel as they move down. The blades also act to stop liquids from going past them as they dispense. Once a syringe has liquid inside, insert the piston and push down on one side. This will allow air to escape and ensures the piston sits directly on the fluid without an air gap. When bottom filling using a barrel filler, the piston is pushed down and moves up as the liquid is fed into the syringe barrel. Pistons can provide a barrier seal for liquids placed inside. But for more protection when dispensing watery liquids and Cyanoacrylate adhesives, use our filter trap in the airline adapter assembly to your syringe dispenser.
