Home > Retainers > 918-034-000




8 Ounce Size Slotted Cartridge Retainer

Our precision components provide safe and leak free fluid dispensing from cartridges. This aluminium retainer body is used with an air cap for pressurising all 8 Ounce dispensing cartridges. A safe and leak free high pressure reservoir system.

918-031-000 6oz Cartridge Retainer Techcon


237cc size aluminium cartridge retainer body.  Accepts all 8oz size cartridges. Bayonet push and twist fitting to the air cap or when used with TS series applicator gun handles. This item is industrial grade safe up to 100 psi air pressure.

Item is used with TS950 pneumatic cartridge guns or TS16 manual cartridge guns as well as with an air cap when used on a bench stand or to feed material to dispensing valves.

Slotted bodied version so cartridge plunger can be seen as it reaches the bottom. 1.70 Inch outer diameter by 8.92 Inch long.  Slotted version here.

  Part ID: 918-034-000
  Materials: Aluminium/ Steel
  Colour: Black
  Size: 8 Ounce
  Max Pressure: 100 PSI
  Use With: 918-001-004 / TS16/ TS950

Adhesive Dispensing Ltd provide a wide range of equipment options for dispensing almost all assembly fluids - from watery liquids, solvents, primers and activators through to thick pastes, sealants, silicones, gels and epoxies.


More Info Part No.

Material

Size Lead Time

Pack

Price GBP Add
918-034-000 918-034-000
Slotted Retainer
Aluminium 8 oz 24 Hours 1  each

More Info Part No.

Material

Size Lead Time

Pack

Price GBP Add
918-046-000 918-046-000
Non Slotted Retainer
Aluminium 8 oz 24 Hours 1  each
918-001-004
Cartridge Air Cap
Nylon 2.5,6,8,12 oz 24 Hours 1  each
918-001-007
Air Cap Gasket
Rubber 2.5, 6, 8, 12 oz 24 Hours 1   each
918-000-002
Cap Air Hose
PU All 24 Hours 1  each
534
Air Cap Hose Fitting
Nylon All 24 Hours 1  each
534A quick connect techcon 534A
Air Cap Hose Fitting
Nylon All 24 Hours 1  each
AD16 Manual Cartridge Applicator Guns AD16-80
Manual Cartridge Gun
Steel/Aluminium 8 oz 24 Hours 1   each
AD16 Manual Cartridge Applicator Guns AD16-80KIT
Manual Kit Cartridge Gun
Steel/Aluminium 8 oz 24 Hours 1   each
TS950-80-HA
Pneumatic Cartridge Gun
Steel/Aluminium 8 oz 24 Hours 1   each

More Info Part No.

Specs

Colours Lead Time

Pack

Price GBP Add
Industrial grade cartridges and plungers for controlled dispensing of sealants, adhesives, glues, silicones, solvents, pastes and resins. All cartridges feature a 1/4 Inch nozzle thread.  Cartridges are safe for use to 100 psi pressure and are certified silicone free plastics. Read more...
Cartridge HDPE Adhesive Dispensing Techcon Semco TS80C
8oz Cartridge HDPE
1.59" OD/ 8.82" Long Natural 24 Hours 10   pack
Cartridge HDPE Adhesive Dispensing Techcon Semco TS80CKIT
8oz Cartridge & Plunger Kit
1.59" OD/ 8.82" Long Natural/ White 24 Hours 10   pack
Cartridge HDPE Adhesive Dispensing Techcon Semco TS80C-LD-250
8oz Cartridge LDPE
1.59" OD/ 8.82" Long Natural 72 Hours 250   pack

Cartridge Plunger Adhesive Dispensing Techcon TS1WP
Cartridge Plunger MDPE 2.5, 6, 8 and 12 Ounce only
1.59" OD Natural 24 Hours 10   pack
Cartridge Plunger Adhesive Dispensing Techcon TS1P
Cartridge Plunger LDPE 2.5, 6, 8 and 12 Ounce only
1.59" OD Blue 24 Hours 10   pack
Cartridge Plunger Adhesive Dispensing Techcon TS1PB
Cartridge Plunger LDPE 2.5, 6, 8 and 12 Ounce only
1.59" OD Black 24 Hours 10   pack
Cartridge Plunger Adhesive Dispensing Techcon TS1WP-RIB
Cartridge Plunger MDPE 2.5, 6, 8 and 12 Ounce only
1.59" OD Natural 24 Hours 10   pack

More Info Part No.

Specs

Colours Lead Time

Pack

Price GBP Add
Reusable flange end caps and threaded tip caps for sealing both ends of the cartridge air tight once materials have been transferred into them. Supplied in sealed packs with labels and batch codes. Cartridge caps are certified silicone free plastics. Read more...
Cartridge End Cap Flange Seal Adhesive Dispensing TS2C
End Cap LDPE 2.5, 6, 8 and 12 Ounce only
40mm Dia. Red 24 Hours 10   pack

AD3PB AD3PB
Tip Cap Threaded Seal HDPE
21mm Dia. Blue 24 Hours 10   pack
TS3P Cartridge Tip Cap Red 1/4" Adhesive Dispensing TS3P
Tip Cap Threaded Seal HDPE
21mm Dia. Red 24 Hours 10   pack
TS3P Cartridge Tip Cap Red 1/4" Adhesive Dispensing TS6P-RED
Tip Cap Threaded Seal HDPE
21mm Dia. Red 24 Hours 10   pack
TS3P Cartridge Tip Cap Red 1/4" Adhesive Dispensing TS6P-BLACK
Tip Cap Threaded Cap
21mm Dia. Black 2-3 Weeks 1000   pack
TS3P Cartridge Tip Cap Red 1/4" Adhesive Dispensing TS4P-RED
Tip Cap Push-In Cap
21mm Dia. Red 1-2 Weeks 1000   pack
TS3P Cartridge Tip Cap Red 1/4" Adhesive Dispensing TS4P-BLACK
Tip Cap Push-In Cap
21mm Dia. Black 2-3 Weeks 1000   pack
TS3P Cartridge Tip Cap Red 1/4" Adhesive Dispensing TS4P-GREEN
Tip Cap Push-In Cap
21mm Dia. Green 2-3 Weeks 1000   pack

More Info Part No.

Specs

Colours Lead Time

Pack

Price GBP Add
Industrial dispensing nozzles with 1/4 Inch thread for leak free attachment to cartridges and dispensing valves. Supplied in sealed packs with labels and batch codes. Cartridge nozzles are safe to 100 PSI and are certified silicone free plastics. Read more...
Adhesive Dispensing Nozzle Cartridge Techcon Semco TS216
Standard Nozzle
2.5" L x 1/16" ID HDPE Natural 24 Hours 10   pack
Adhesive Dispensing Nozzle Cartridge Techcon Semco TS218
Standard Nozzle
2.5" L x 1/8" ID HDPE Natural 24 Hours 10   pack
Adhesive Dispensing Nozzle Cartridge Techcon Semco TS218-LD
Standard Nozzle
2.5" L x 1/8" ID LDPE Natural 24 Hours 50   pack
Adhesive Dispensing Nozzle Cartridge Techcon Semco TS416
Standard Nozzle
4.0" L x 1/16" ID HDPE Natural 24 Hours 10   pack
Adhesive Dispensing Nozzle Cartridge Techcon Semco TS416-LD
Standard Nozzle
4.0" L x 1/16" ID LDPE Natural 24 Hours 50   pack
Adhesive Dispensing Nozzle Cartridge Techcon Semco TS418
Standard Nozzle
4.0" L x 1/8" ID HDPE Natural 24 Hours 10   pack
Adhesive Dispensing Nozzle Cartridge Techcon Semco TS432
Standard Nozzle
4.0" L x 1/32" ID HDPE Natural 24 Hours 10   pack
Adhesive Dispensing Nozzle Cartridge Techcon Semco TS432-LD
Standard Nozzle
4.0" L x 1/32" ID LDPE Natural 24 Hours 50   pack
Adhesive Dispensing Nozzle Cartridge Techcon Semco TS490
Standard Nozzle
4.0" L x 3/32" ID HDPE Natural 24 Hours 10   pack
Nozzle Cartridge Ribbon Spreader Adhesive Dispensing TS1050
Ribbon Spread Nozzle
4.0" L x 0.50" W HDPE Natural 24 Hours 10   pack
Nozzle Cartridge Ribbon Spreader Adhesive Dispensing TS1075
Ribbon Spread Nozzle
4.0" L x 0.75" W HDPE Natural 24 Hours 10   pack
Nozzle Cartridge Ribbon Spreader Adhesive Dispensing TS1100
Ribbon Spread Nozzle
4.0" L x 1.0" W HDPE Natural 24 Hours 10   pack
Nozzle Cartridge Ribbon Spreader Adhesive Dispensing TS1175
Ribbon Spread Nozzle
4.0" L x 1.75" W HDPE Natural 24 Hours 10   pack

Delivery: Products shipped by courier on a tracked and insured service for stock items.

Products on a longer lead time or built to order will be sent as soon as available. Customers are informed of ship dates and updates.

Typical Applications:- Cartridge retainers are for use with air cap and air hose. Use to pressurise liquids and pastes up to 100 PSI.

Use with most liquids, pastes, epoxies, gels, solvents, adhesives, fluxes, lubricants, paints, inks, solder creams, braze pastes and many more assembly fluids.

Specifications:

Material: Aluminium
Colour: Black
Capacity: 8 Ounce (237cc or 237ml)
Inner Diameter: 42.92mm (1.70 Inch)
Total Length: 226.6mm (8.92 Inch)

Connection Type: Bayonet Twist to Air Cap
Maximum Pressure: 100 PSI (6.89 Bar)
Air Flow Pattern: Straight
Description: Cartridge Body Retainer
Features: Industrial Grade




Cartridge Pages

    Silicone and chloride free materials
  Industrial grade safe to 100 psi
  Resistant to aggressive fluids and solvents
  Use with 918-001-004 Air Cap
  Available direct from stock
  12 month warranty
