> Home > Equipment > Guns > Dual Guns > ADCBA-25D




50ml Pneumatic Cartridge Gun for Epoxy Dispensing

Cartridge gun dispensers are designed for the controlled application of two component materials direct from 50ml 1:1 ratio dispensing cartridges. This gun includes an easy to use adjustable regulator to ensure a consistent flow of adhesive and fast air release. This is rod driven so provides a very controlled pressure on the dual pistons in the cartridge.

50ml pneumatic 1:1 ratio dual cartridge gun


For epoxies, silicones, polyurethanes, adhesives and other materials that are supplied in 50ml two part, side-by-side 1:1 ratio mix cartridges with the use of a static mixing nozzle.

The lightweight and durable construction of our pneumatic guns make them well suited for many assembly operations in various markets such as aerospace, electronics, construction and automotive. This gun features a built-in adjustable air regulator to set flow rates.

Connect this gun to an air supply. The dual cartridge is pushed into the pivoting gun retainer and clicked in place. Air pressure is dispensed onto the rods pushing down on the pistons within the cartridge. Guns fit comfortably into the hand for use over long periods of time and minimum risk of repetitive strain injury.


Thrust: 0.71 kN (71kgf) at 50 psi (3.4 bar).
Weight: 650 Gram
Lead Time:
Ships Within 24 Hours (Stock Item)

All products are CE approved product with a 1 Year warranty. This gun works with all pre-filled 50ml adhesive cartridges 1:1 ratio.


More Info Part No. Size Type Ratio Max Pressure Price GBP Add
ADCBA-25D Gun 50ml 1:1 Ratio Adhesive Dispensing ADCBA-25D
50ml Ratio Dual Gun
50ml Pneumatic Gun 1:1 Only 100 PSI Max    each

Sulzer Mixpac B-System 50ml Adhesive Dispensing 451000
50ml Dual Cartridges
50ml Cartridge Piston Sets 1:1 Only 100 PSI Max    pack 50
static mixer nozzle adhesive dispensing MAQ05-16L
Static Mixer Nozzle
5.3mm 83mm Long x 16 Elements 1:1/2:1 100 PSI Max    pack 50
static mixer nozzle adhesive dispensing MAQ05-24L
Static Mixer Nozzle
5.3mm 115mm Long x 16 Elements 1:1/2:1 100 PSI Max    pack 50

More Info Part No. Size Type Ratio Pressure Price GBP Add
ADCBE-50 Battery 50ml Dual Cartridge Gun ADCBE-50
50ml Ratio Dual Gun
50ml Battery 1:1/ 2:1 1.5kN Battery    each
EDS408M 50ml Air Gun Dual Cartridge Adhesive Dispensing EDS408M
50ml Ratio Dual Gun
50ml Pneumatic 1:1/ 2:1/ 4:1/ 10:1 100 PSI Max    each
Sulzer Mixpack Manual 50ml Dual Guns Adhesive Dispensing ABM-25M1
50ml Ratio Dual Gun
50ml Manual 1:1/2:1 n/a    each

Product Pages


ADCBA-25D Air Gun Features

  Fits all 50ml 1:1/ 2:1 size dual epoxy cartridges
  Easy cartridge load and unload mechanism
  Controlled fast deposit or consistent beads
  Lightweight yet very robust construction
  Fast air exhaust reduces drips or ooze
  Built in adjustable air regulator for flow rate
  Current Lead Time 24 Hours

Adjustable air regulator

Quick cartridge load
