> Home > Guns > Syringe Guns > DG30




30cc Manual Syringe Gun Dispenser

Our Syringe Gun dispensers are designed for the controlled application of pastes, gels, adhesives and fluids. A cost effective quality made syringe dispensing gun for use with standard 30cc/ 30ml size syringe barrels. Ideal for low volume production, re-work or repair work. This version has an adjustable shot feature.
Adhesive dispensing syringe gun dispenser

Syringe Guns offer a low cost dispensing solution for most low to medium viscosity pastes, gels, silicones, greases, adhesives and many other liquids. A portable and lightweight manual dispenser for applying most fluids.

A 7:1 ratio leverage for robust trigger movement. The rod moves once when pressed to provide controlled deposits without drips or ooze. Remove the pin and then set position to smaller shot or larger shots. Simple bayonet twist-on/ twist-off syringe barrel attachment.

Ideal manual gun for deposits or beads of solder paste, solder flux, RTV, silicones, sealants, gels, greases, compounds, PVA glues, general adhesives and many other liquids..

Each syringe gun includes components and this version is supplied with: (1) dispensing barrel reservoir, (1) wiper piston, (1) storage end cap, (1) locking tip cap, (1) dispensing tip. All syringe guns ship direct from stock and include basic instructions for use
.


DG30 Syringe Gun

GBP   each ex. Vat.
Excludes carriage.
Product Code: DG30
Lead Time:
Ships Within 24 Hours

Summary: Manual operated Syringe Gun for use with 30cc size barrels. Bayonet lock secure attachment. Rod lever release. 7:1 ratio leverage to provide easy control over pastes & gels. Basic gun pnly with (1) syringe barrel, (1) piston, (1) end cap, (1) tip cap and (1) dispense tips.


Product Code Qty Price GBP Add
DG30 1   each

DG30 Syringe Gun Kit

GBP   each ex. Vat.
Excludes carriage.
Product Code: DG30-KIT
Lead Time:
Ships Within 24 Hours

Summary: Manual operated Syringe Gun for use with 30cc size barrels. Bayonet lock secure attachment. Rod lever release. 7:1 ratio leverage to provide easy control over pastes & gels. Full gun kit with (20) syringe barrels, (20) pistons, (20) end caps, (20) tip caps and (50) assorted tips. Learn more...


Product Code Qty Price GBP Add
DG30-KIT 1   each

Items are shipped in the UK by a courier on a tracked and insured service with products that are available from stock. Items on a longer lead time will be shipped as soon as they are made available.

Adhesive Dispensing Ltd provide a wide range of equipment options for dispensing almost all assembly fluids - from watery liquids, solvents, primers and activators through to thick pastes, sealants, silicones, gels and epoxies.

  Part ID: DG30
  Materials: Nylon, Polypropylene, Polyethylene, Steel
  Colours: Black
  Syringe Size: 30cc/ 30ml
  Gun Weight: 110 gram (without barrel)
  Gun Length: 265mm (including push rod)
  Gun Height: 135mm
  Warranty: 12 Months
  Commodity Code: 90289090

The guns are robust and handle most liquids and pastes dispensed from them. However, it is important to ensure the O-ring is kept greased with an oil or lubricant. O-rings can become worn or covered in glue so they are available to order from stock as replacements.

The gun is supplied with (1) spare rubber O-ring in the pack. For future replacement, select the 30/55cc size in EPR or Viton. The O-ring is a vital part of this gun assembly to ensure reliable application; select part code P3018EPK, supplied in packs of (10) direct from stock.

General Use: Guns are portable and can be used in a factory production or assembly department as well as for repair and re-work. Guns are commonly used in the field for repair or maintenance applications.

Common Applications:- Dots and beads of solder paste, Dots and beads of solder flux, Grease to bearings, PVA glue to furniture joints, RTV to seal seams, Silicone dots to bond products, Gasket sealant repair, Shots of roach insecticides, General adhesive applications.



  With Barrel, Piston, Caps & Tip
  Strong 7:1 Ratio Hand Lever Leverage
  Controlled Shot Deposits or Beads
  Lightweight yet Robust Construction
  Quick Barrel Bayonet Attachment
  Low Cost Portable Dispensing Solution
  Ships direct from stock
  Buy Gun Only or with Full Barrel/Tip Kit

More Info Part Code

Description

Lead Time Price GBP Add
clear syringe barrel luer lock adhesive dispensing 7300LL1NPK
30cc Size Polypro
Syringe Barrel
AD930-N
Translucent Clear
Barrel Size: 30cc/ 30ml
Length: 118.36mm - 4.66 Inch
ID: 22.63mm - 0.89 Inch
OD: 25.27mm - 0.99 Inch
Pack Size: 50 Pieces
Ships Within 24 Hours   pack
More Info Part Code

Description

Lead Time Price GBP Add
Amber tint syringe barrel adhesive dispensing 7300LL1DPK
30cc Size Polypro
Syringe Barrel
AD930-D
Amber Tint
Barrel Size: 30cc/ 30ml
Length: 118.36mm - 4.66 Inch
ID: 22.63mm - 0.89 Inch
OD: 25.27mm - 0.99 Inch
Pack Size: 50 Pieces
Ships Within 24 Hours   pack
More Info Part Code

Description

Lead Time Price GBP Add
black syringe barrel luer lock adhesive dispensing 7300LL1BPK
30cc Size Polypro
Syringe Barrel
AD930-B
Black Opaque
Barrel Size: 30cc/ 30ml
Length: 118.36mm - 4.66 Inch
ID: 22.63mm - 0.89 Inch
OD: 25.27mm - 0.99 Inch
Pack Size: 50 Pieces
Ships Within 24 Hours   pack
More Info Part Code

Description

Lead Time Price GBP Add
syringe barrel wiper piston white 7300009WPK
30cc/55cc Size
White Wiper Piston
AD930-WW
Piston Size: 30cc & 55cc/ 30ml & 55ml
Height: 16.00mm - 0.63 Inch
OD: 23.0mm - 0.91 Inch
Material: Polyethylene Low Density
Pack Size: 50 Pieces
Ships Within 24 Hours   pack
More Info Part Code

Description

Lead Time Price GBP Add
black rubber wpier piston adhesive dispensing  30T-2A
30cc/55cc Size
Rubber Piston
Black Colour
Piston Size: 30cc & 55cc/ 30ml & 55ml
Height: 19.25mm - 0.64 Inch
OD: 22.63mm - 0.89 Inch
Material: Rubber
Pack Size: 50 Pieces
Ships Within 24 Hours   pack
More Info Part Code

Description

Lead Time Price GBP Add
orange syringe end cap seal snap on 730000CRPK
30cc/55cc Size
End Cap Seal
AD930-ECO
Barrel Size: 30cc & 55cc/ 30ml & 55ml
Material: Polyethylene
Colour: Orange
Type: Snap-On End Flange Cap Seal
Pack Size: 50 Pieces
Ships Within 24 Hours   pack
More Info Part Code

Description

Lead Time Price GBP Add
DCK600
Tip Kit Assortment
Hard Case
TN00DKIT
Tip Sizes: 14GA to 32GA
Materials: Polyethylene, Polypro, S/S
Colours: Assorted
Type: TE, TTN, TLC, Tip Cap
Pack Size: 144 Pieces
Ships Within 24 Hours   each
More Info Part Code

Description

Lead Time Price GBP Add
P3018EPK
Rubber O-Ring
EPR Material
30cc Size
For Gun Sizes: 30cc and 55cc
Material: EPR Rubber
Colour: Black
Type: Seals Gun Rod End
Pack Size: 10 Pieces
Ships Within 24 Hours   pack
