Benchtop Dispensing Robot
510mm x 620mm Work Area



Easy to program robots for making exact dots, beads, arcs and circles of most gels, fluids, pastes and adhesives. This version gives a working maximum dispensing area of 510mm by 620mm. Robots are supplied with LCD teach pendant, dispense controller & CE start/stop box. They include all I/O cables, connectors, pipes and fittings.


Robots provide precise control over adhesive placement, from exact beads, to repeat timed dots or potting of components. Programming is simple via a teach pendant. Even complex patterns can be created quickly. Storage is to internal flash memory allowing for up to 255 programs to be created. High speeds are achieved reducing time spent hand applying adhesives. Accuracy of placement and volume of fluid ensures zero waste, mess and error. Robots will dispense most materials including adhesives, pastes, epoxies, gels, silicones, sealants, RTV's, oils, grease, anaerobics, cyanoacrylates, inks and lubricants.

Janome dispensing robot JR2203N

The J2600 series robots have a maximum base work area of 510mm x 620mm.  In 2, 3 or 4 axis indexing.  Use 2 axis for simple lines or dots to flat components.  3 axis will allow the head to index vertically to a height of 150mm.  4 axis for 360 degree head rotation (R) to dispense to the sides of components or around the outside of products.  All robots are supplied with a digital syringe controller, I/O cable, CE compliance start/ stop box, teach pendant, airline hoses, syringe bracket, slide adjustment and detailed instruction manuals.


Suitable for...
Make dots of adhesives Dotting
Make beads of adhesives Beading
Potting of components Potting
Bonding of components Repairs
Sealing of components Gasketing
Dispense lubricants and greases Lubricating
Sealing




Adhesive Dispensing Ltd provide a wide range of equipment options for dispensing almost all assembly fluids - from watery liquids, solvents, primers and activators through to thick pastes, sealants, silicones, gels and epoxies.

Part No Robot Dispense Area

Number of Axis

Price
J2602 510mm x 620mm 2 POA
J2603 510mm x 620mm x 150mm 3 POA
J2604 510mm x 620mm x 150mm 4 POA

1 x Base Robot with power cord
1 x LCD Teach Pendant with cable
1 x CE Compliance kit - start/ stop box
1 x 30/55cc Syringe Mount slide
1 x TS250 Digital Pneumatic controller
1 x TS250 airline kit/ power kit
1 x I/O Cable to controller
1 x CD-ROM with user guides
1 x Syringe Kit (30cc and 55cc size)
1 x Tip Kit (145 assorted tips)
Copyright  2008 Adhesive Dispensing Ltd. All rights reserved. Copyright  2008 Adhesive Dispensing Ltd. All rights reserved. Copyright  2008 Adhesive Dispensing Ltd. All rights reserved.

Precision Robots




Barrels


End Caps

Adapters
Copyright  2008 Adhesive Dispensing Ltd. All rights reserved.
Tip Caps

Air-Powered Dispensers * Industrial Dispensing Components * Precision Dispense Valve Systems * XYZ Bench Robots

Adhesives * Packaged Components * Techkits * RatioPacks * Hingepacks * Syringe Barrels * Cartridges * Nozzles


|  Privacy   |   Terms   |  Accounts  |

Prices are in UK pounds.  Vat is not charged on orders placed outside the EU and any EU orders are exempt from VAT only if a valid company VAT number is provided to us at time of order or before shipping.  Products are covered by a 12-month warranty against faults and malfunction.  All orders online are encrypted for safety and security.  Please read our privacy agreement for details.  We also process phone or fax payments by credit and debit card.  Please contact our accounts department if you would like to open a credit account with us.

Disclaimer: While reasonable efforts have been made to ensure all information on this website is accurate, Adhesive Dispensing Ltd. do not assume responsibility for any errors or omissions. All specifications, illustrations, data and prices are subject to change without notice.

Copyright  2005 - 2017 Adhesive Dispensing Ltd. All rights reserved.




  Support

  Literature
  Full Catalogue
  Dispense Tips Brochure
  Syringe Barrels Brochure
  Cartridges Brochure

  Information
  Important Safety Information
  Viscosities Chart

  Contact Us
  Equipment Recommendations
  Request a Quote
  Technical Support
  Applicator Assist

  Shipment of this product


Items are shipped in the UK by a courier on a tracked and insured service for all items that are available from stock.



  Concealed Guide Rail Housing


This prevents contamination of the guide rail, which allows the J2600 series robots to operate in the harshest environments. The concealed guide rail housing is a design feature that makes the robot an ideal solution for a wide variety of fluid dispensing applications.



  Interface


The robot provides ample I/O for even the most complicated assembly operations. The J2600 series desktop robot is supplied standard with 16 inputs and 16 outputs and an optional addition of 8 inputs and 8 outputs. The robot also has two COM ports for communications with the optional PC software and vision systems. In addition the robot has built-in PLC functions, that can operate independently of the robot, that use portions of the robots I/O.




  CE Certification


Robots are also provided with CE certification and come with a remote operation start and stop box and a safety interlock connector.
