This product is certified silicone free


Static mixer nozzles 5.4mm ID x 7 mix elements

High density moulded static mixer nozzles with bayonet attachment to 50ml size dual cartridges. Stepped and tapered end design for direct dispensing of epoxies or attachment of reducer fitting when using smaller luer lock needle tips. Silicone free and industrial grade.



MA3.0-07S static mixer nozzle


Bayonet inlet, helical static mixer for 50ml and 75ml cartridges.  Stepped outlet that can be cut back to increase orifice size and increase flow rates.  These mixer nozzles are suitable for 1:1 and 2:1 ratio two-component materials.  They have white elements and are constructed of high grade polypropylene. High quality mixer nozzles for use with twin cartridges.  All items are industrial grade safe and silicone free. 5.4mm inner diameter x 7 mixing elements.

ma6.3-17S Static mixer nozzle sulzer



If a higher level of control for smaller deposits is required, use our part code LA05-00 with this mixer nozzle. It threads over the end of the nozzle to provide a luer lock tip attachment. This allows the use of our full range of dispensing tips to control the  epoxy or material better.

This reducer fitting is made from high density plastic and is available in sealed packs of 100 direct from stock.


Specifications

Part ID: MA5.4-07S

50ml dual cartridges

Material: Polypropylene
Colour: Natural Outer, White Elements
Inner Diameter: 5.4mm
Elements: 7
Length: 56mm
Volume: 0.8ml
Details: Industrial grade, Silicone Free
Lead Time: * Ships in 24 Hours

Size Pack Size

Part Number

Price Buy
5.4mm ID 100 MA5.4-07S  per pack
