Recirculatory Fume Filter Cabinet

Fume Extraction System Adhesive Dispensing

High performance systems for the removal of adhesive and solvent fumes from the work bench. Versatile products provide a safe and clean working environment when handling/ dispensing liquids with odours. Supplied complete and ready to use out of the box.


Contain and filter for a cleaner, healthier working environment within dental labs, electronic design and rework, pharmaceutical labs, education and more. For use in numerous situations where external venting is impractical but where contaminant capture and filtration is necessary.

Applications include the filtration of fume, vapour and particulates emanating from monomers, adhesives, hazardous powders/particulates, conformal coatings, resins, sealants, solders, light grinding particles and dusts, organic solvents etc.

Description

Fan/filter casing (steel construction finished in dove grey) - clear PETG folding plastic fume shield - particulate (Intake Filter) - bonded carbon filter - 2 x centrifugal blowers, external rotor motor type brushless, UL, VDE and CSA approved - sealed electrical wiring and switch, downstream of filters. T700S-C has a dual airspeed function to facilitate higher vapour adsorption.
*110V 60Hz version available if required.

Operation

The folding PETG shield can be stored if not required thus reducing the unit footprint considerably. Handling and / or use of potentially harmful substances is carried out in front of the intake filter area. Cleaned air is vented to the top rear of the units.


Adhesive Dispensing Ltd provide a wide range of equipment options for dispensing almost all assembly fluids - from watery liquids, solvents, primers and activators through to thick pastes, sealants, silicones, gels and epoxies.

Specification

Part ID: T700SC
Fan Motor Spec: 230V 50Hz 105W
Air Volume at Free Air: 710 m3/hr
Air Velocity at Filter Face: 0.57 m/sec
Air Velocity at Hood Face: 0.55 m/sec
Noise Level: 62 dB (A)
Weight: 37 kg
Lead Time: Usually Ships 5-7 days

Part No. Description Price Buy
T700SC Air Filtration Cabinet Axial Dual Fan and Filters  each


Filtration

The particulate (intake) filter is a three stage graduated fibre filter (filtration to 5.0 micron particles) with a high 'dust' holding capacity for long life. (Optional HEPA filters available to 0.3micron particles). This is followed by a high grade bonded carbon filter. (7.0kg T700).

The process of filtration, adsorption and dilution, operator exposure to potentially hazardous substances is vastly reduced.

This unit is designed for immediate operator protection from concentrations of airborne contaminants whereby all gases, fumes, vapours and particulates within the hood enclosure are filtered and cleaned air is exhausted to the right rear of the cabinet. It is not recommended for continual usage, i.e. production applications, particularly in confined and/or badly ventilated areas.

See larger TechFlo filtration/extraction cabinets for higher specification requirements. Demonstrating adequate control of the risks to the health of employees students and the general public, from dusts, powders, mists, fumes and vapours is the fundamental requirement of the Control of Substances Hazardous to Health (CoSHH).
