Flexible Teflon Tube Dispense Tip
30 Gauge
2 Inch Long |
|
Dispensing tip with
long flexible translucent clear tube and threaded luer lock colour
coded hub for secure attachment to syringe barrels or dispense
valves. Ideal for use with Cyanoacrylates and other low viscosity
liquids as adhesives will not stick to the tube or clog.
The soft clear shaft allows fluid flow to be seen. |
|
|
|
A flexible 30 gauge lavender tip with 2
Inch long Teflon tube. Threaded polypropylene hub. Ideal for use with cyanoacrylates,
solvents and other low to medium viscosity fluids. Teflon tube
will not clog rapidly during use. Attaches to syringe
barrels or dispenser
bottles.
Clear
translucent tube attached below the colour coded hub allows fluid flow to be
viewed during dispensing. 0.012 Inch ID. Supplied in sealed packs of 50
or bulk packs of 1000. Shaft tube length of 2.0 Inch
(50.8mm).
Adhesive Dispensing Ltd provide a wide range of equipment options for dispensing almost all
assembly fluids - from watery liquids, solvents, primers and activators
through to thick pastes, sealants, silicones, gels and epoxies.
|
|
|
|
|
|
|
Materials: Teflon, Polypropylene
Colour: Lavender Hub, Clear Tube Tip ID:
0.305mm (0.012 Inch) Tip OD:
0.610mm (0.024 Inch) Tip Tube Length: 50.80mm (2.0 Inch)
Connection Type: Double Helix Luer Lock
Maximum Pressure: 100 PSI (6.89 Bar)
Flow Pattern: Straight
Description: Tip for CA Adhesives
Features: Silicone-Free, Industrial Grade
Pack Size: 50
|
|
|
|
|
Delivery: Products
shipped by courier on a tracked and
insured service for stock items.
Products on a
longer
lead time or built to order will be sent as soon as available. Customers are informed of
ship dates and updates.
Typical Applications:-
Use these tips for deposits of Cyanoacrylate adhesives, inks, oils,
primers, liquids, acivators and many other assembly fluids.
For
viscous pastes and epoxies, use our smooth flow tapered tips. |
|
|
|
|
|
|
Part |
Gauge |
Length |
Colour |
Inner Diameter |
Outer Diameter |
Lead Time |
Price GBP |
Add |
TF14-1/2 |
14 |
12.7mm |
Olive |
1.676mm |
2.083mm |
24 Hours |
pack 50 |
|
TF14-1 |
14 |
25.4mm |
Olive |
1.676mm |
2.083mm |
48 Hours |
pack 50 |
|
TF14-15 |
14 |
38.1mm |
Olive |
1.676mm |
2.083mm |
72 Hours |
pack 50 |
|
TF14-2 |
14 |
50.8mm |
Olive |
1.676mm |
2.083mm |
72 Hours |
pack 50 |
|
TF14-3 |
14 |
76.0mm |
Olive |
1.676mm |
2.083mm |
72 Hours |
pack 50 |
|
TF16-1/2 |
16 |
12.7mm |
Purple |
1.346mm |
1.650mm |
24 Hours |
pack 50 |
|
TF16-1 |
16 |
25.4mm |
Purple |
1.346mm |
1.650mm |
48 Hours |
pack 50 |
|
TF16-15 |
16 |
38.1mm |
Purple |
1.346mm |
1.650mm |
48 Hours |
pack 50 |
|
TF16-2 |
16 |
50.8mm |
Purple |
1.346mm |
1.650mm |
24 Hours |
pack 50 |
|
TF16-3 |
16 |
76.0mm |
Purple |
1.346mm |
1.650mm |
48 Hours |
pack 50 |
|
TF18-1/2 |
18 |
12.7mm |
Pink |
1.067mm |
1.372mm |
24 Hours |
pack 50 |
|
TF18-1 |
18 |
25.4mm |
Pink |
1.067mm |
1.372mm |
48 Hours |
pack 50 |
|
TF18-15 |
18 |
38.1mm |
Pink |
1.067mm |
1.372mm |
72 Hours |
pack 50 |
|
TF18-2 |
18 |
50.8mm |
Pink |
1.067mm |
1.372mm |
72 Hours |
pack 50 |
|
TF18-3 |
18 |
76.0mm |
Pink |
1.067mm |
1.372mm |
72 Hours |
pack 50 |
|
TF20-1/2 |
20 |
12.7mm |
Yellow |
0.864mm |
1.168mm |
24 Hours |
pack 50 |
|
TF20-1 |
20 |
25.4mm |
Yellow |
0.864mm |
1.168mm |
24 Hours |
pack 50 |
|
TF20-15 |
20 |
38.1mm |
Yellow |
0.864mm |
1.168mm |
24 Hours |
pack 50 |
|
TF20-2 |
20 |
50.8mm |
Yellow |
0.864mm |
1.168mm |
24 Hours |
pack 50 |
|
TF20-3 |
20 |
76.0mm |
Yellow |
0.864mm |
1.168mm |
24 Hours |
pack 50 |
|
TF22-1/2 |
22 |
12.7mm |
Black |
0.711mm |
1.016mm |
24 Hours |
pack 50 |
|
TF22-1 |
22 |
25.4mm |
Black |
0.711mm |
1.016mm |
24 Hours |
pack 50 |
|
TF22-15 |
22 |
38.1mm |
Black |
0.711mm |
1.016mm |
24 Hours |
pack 50 |
|
TF22-2 |
22 |
50.8mm |
Black |
0.711mm |
1.016mm |
24 Hours |
pack 50 |
|
TF23-1/2 |
23 |
12.7mm |
Blue |
0.660mm |
0.965mm |
24 Hours |
pack 50 |
|
TF24-1/2 |
24 |
12.7mm |
Red |
0.559mm |
0.864mm |
24 Hours |
pack 50 |
|
TF24-1 |
24 |
25.4mm |
Red |
0.559mm |
0.864mm |
24 Hours |
pack 50 |
|
TF30-1/2 |
30 |
12.7mm |
Lavender |
0.305mm |
0.610mm |
24 Hours |
pack 50 |
|
TF30-1 |
30 |
25.4mm |
Lavender |
0.305mm |
0.610mm |
72 Hours |
pack 50 |
|
TF30-1.5 |
30 |
38.1mm |
Lavender |
0.305mm |
0.610mm |
72 Hours |
pack 50 |
|
TF30-2 |
30 |
50.8mm |
Lavender |
0.305mm |
0.610mm |
72 Hours |
pack 50 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
