Pinch Tube Dispensing Valve

An air operated dispense valve for applying repeat dots, controlled beads or potting of most adhesives and liquids. Uses replaceable low cost pinch tubes to eliminate cleanup and maintenance. Operates from a timed dispenser with fluid feed from pressure pot, cartridge or syringe.

TS1212 Pinch Tube Valve Adhesive Dispensing

Specifications

Wetted Parts: Polyethylene
Size: 83mm L x 40mm Diameter
Valve Weight: 114  Gram
Fluid Viscosity Range: 1 to 45,000 CPS

Flow Rate: 0.54 GAL/ Min (water) @ 60 psi
Repeatability: +/- 0.56%
Material Inlet Connection: Female Luer Lock
Material Outlet Connection: Male Luer Lock
Cycle Rate: Up to 500 cycles/ minute

Minimum Shot Size: 0.007cc/ ml
Maximum Fluid Pressure: 100 psi
Activation Air Pressure: Minimum 60 psi
Warranty: 1 Year
Data Sheet

The pinch tube valve is a compact and cost effective device for dispensing very thin liquids, semi-viscous materials, cyanoacrylates, anaerobics, solvents, UV cure adhesives and two-component fluids. For repeat dots, beads or potting of liquids fed from a syringe, cartridge or pressure pot. The only part of the valve that makes contact with the liquid is the low cost replaceable pinch tube assembly. This makes the TS1212 valve ideal for aggressive or curable liquids with no risk of the material setting and damaging expensive parts.

Compact and easy to set up, this valve is operated by any of our valve controllers. The controller provides a timed pulse of air pressure to open the TS1212 pinch tube, allowing the adhesive or liquid to flow. A spring loaded shut-off provides the ability to make micro dots if required with no drips between shots. The shot size is determined by the time setting on the controller, the fluid pressure, the amount of opening set on the adjustable stroke control and the size of needle tip used.

The connecting link between reservoir and TS1212 is a fluid line that offer a safe luer lock connection and are suitable for use with most liquids and adhesives. Use Teflon lined or Teflon tips for cyanoacrylates, General Purpose tips for other fluids and Tapered tips for viscous liquids.
