19 Litre Pressure Pot with 0-60 psi Air Regulator

19 Liter Pressure Pot Tank Adhesive Dispensing

Our fluid tanks keep a steady fluid pressure, eliminate fluid contamination and evaporation, and eliminate fumes. This version is 0-60 psi and supplied complete with fluid lines and fittings. Use the adjustable regulator on the lid to provide a constant flow of liquid.


The TS1265 Pressure Pot is designed to accommodate most low to medium fluids, adhesives, solvents and UV's.  Pot accommodates 1/4" OD feed tubing with stainless steel compression fittings for a continuous fluid path from the reservoir inside the pot to the metering valve.

Airtight seals ensure no leakage problems.  Built in adjustable 60 psi air regulator and gauge. Wide open mouth for easy access.  Handles fluid viscosity up to 35,000 cps. Air port quick connect fitting and top ported outlet.  Type 304 stainless steel.


Adhesive Dispensing Ltd provide a wide range of equipment options for dispensing almost all assembly fluids - from watery liquids, solvents, primers and activators through to thick pastes, sealants, silicones, gels and epoxies.

Specifications

Part ID: TS1265
Weight: 10.5kg
Viscosity Range: Liquids up to 35,000 CPS
Max Fluid Pressure: 60 psi ( 4 Bar)
Air Inlet: 1/4" thread inlet
Material Outlet: 1/4" OD or 1/8" male luer lock to fluid line
Materials: Type 304 stainless steel
Lead Time: Usually Ships in 5-7 Days

  Ideal for use with most liquids - stainless body
  Wide mouth opening
  0-60 psi adjustable regulator and gauge
  Either 1/4" tubing or female luer lock fluid lines
  6mm push fit air in
  1 Year Warranty

60 psi safety pressure easily handles fluid with viscosity up to 35,000 cps. Air port quick connect 6mm fitting and top ported outlet. Easy connect to any air supply.

Datasheet PDF 119k


Description

Part Code

Price Buy
19 Litre Pressure Pot TS1265    each
