Cartridges are manufactured to the very highest possible quality
delivering exceptional performance and consistency. From moulding to
packaging, cartridges are guaranteed to be free of silicone
contaminants and imperfections.
Cartridge reservoir in high
density polyethylene with wiper plunger in a kit of 10 x
TS60C cartridges and 10 x TS1WP
plungers. Suitable for handling most
materials including solvent based fluids.
Suitable for use in cartridge
pressurised cartridge retainers and caps.
Cartridges feature a 1/4 Inch NPT (6mm) female thread dispensing orifice for secure
nozzles or 1/4 Inch threaded
Disposable plastic cartridges are available
in 2.5, 6, 8, 12, 20, 32 oz. (approximate metric value 75, 177, 237,
355, 591, 960cc) and 1/10th gallon capacities. Manufactured in high-density natural polyethylene
All sizes feature a 1/4 Inch NPT (6mm)
female thread dispensing orifice for secure attachment of
nozzles or 1/4 Inch threaded fittings. These items ship from our UK warehouse direct from
stock - no delays. We stock manual and applicator guns
for these cartridges.
Adhesive Dispensing Ltd provide a wide range of equipment options for dispensing almost all
assembly fluids - from watery liquids, solvents, primers and activators
through to thick pastes, sealants, silicones, gels and epoxies.
TS60CKIT Cartridge/ Plunger Kit
Lead Time: Usually Ships 24
Cartridge Material: High Density Polyethlene
Plunger Material: Medium Density PE
Colour: Natural Plunger Colour: Natural Capacity: 6 Ounce (177cc or
177ml) Outer Diameter:
42.92mm (1.69 Inch) Inner Diameter: 40.40mm (1.59 Inch)
Total Length: 181.0mm (7.14 Inch) Connection Type: 1/4 Inch NPT Female Thread Maximum Pressure: 100 PSI (6.89 Bar) Flow Pattern: Straight Description: Sealant type cartridge
Features: Silicone-Free, Industrial Grade
shipped by courier on a tracked and
insured service for stock items.
Products on a
lead time or built to order will be sent as soon as available. Customers are informed of
ship dates and updates.
Cartridges are moulded in high density
plastics and have much thicker walls than a standard silicone caulking
internal bore has no taper and this ensures the plunger moves
consistently down without restriction.
All cartridges use a 1/4
internal thread for leak free nozzle attachment.
Use with most
liquids, pastes, epoxies, gels, solvents, adhesives, fluxes, lubricants,
paints, inks, solder creams, braze pastes and many more assembly fluids.
Silicone and chloride free plastics
Industrial grade safe to 100 psi
Resistant to aggressive fluids and solvents
High density moulding (HDPE)
1/4 Inch NPT thread to accept nozzles
Compatible with industry standard guns
