10cc Manual Syringe Gun Dispenser with Component Kit for UV Adhesives

Our Syringe Gun dispensers are designed for the controlled application of pastes, gels, adhesives and fluids. A cost effective quality made syringe dispensing gun for use with standard 10ml size syringe barrels. Ideal for low volume production, re-work or repair work. This version is shipped ewith black colour barrels and pistons for use with all UV cure adhesives.

TS710SG-UV Syringe Gun Dispenser

Syringe Guns offer a low cost dispensing solution for most low to medium viscosity pastes, gels, silicones, greases, adhesives and many other liquids. A portable and lightweight manual dispenser for applying most fluids.

A 7:1 ratio leverage for effortless trigger movement. The rod moves 3mm (1/8 Inch) once pressed to provide controlled deposits without drips or ooze. Push the top button to release and pull back the plunger rod to remove the barrel. Simple bayonet twist-on/ twist-off syringe barrel attachment.

Ideal manual gun for deposits or beads of solder paste, solder flux, RTV, silicones, sealants, gels, greases, compounds, PVA glues, general adhesives and many other liquids..

Each Syringe Gun includes a kit of components and this version is supplied with: (50) black colour dispensing barrel reservoirs, (50) blakc rubber pistons, (50) storage end caps, (50) locking tip caps, (100) assorted dispensing tips.

All manual syringe guns ship direct from stock in sealed packs and include instructions for use.

Parts included in the kit are: -

(1) 3cc Manual Gun Part TS710SG
(50) 10cc Black Polypro Syringe Barrel Part 7030LL1BPK
(50) 10cc Black Rubber Piston Part AD910-RP
(50) 10cc Orange End Cap Seal Part 710000CRPK
(50) Orange Tip Cap Seal Part 7015LLPK
(20) 18GA Green Dispense Tip Part TE718050PK
(20) 20GA Pink Dispense Tip Part TE720050PK
(20) 22GA Blue Dispense Tip Part TE722050PK
(20) 25GA Red Dispense Tip Part TN25
(20) 27GA Dispense Tip Part TN27E

TS710SG-UV Syringe Gun Kit

GBP   each ex. Vat.
Excludes carriage.
Product Code: TS710SG-UV
Lead Time:
24 Hours

Summary: Manual operated Syringe Gun for use with 10cc size barrels. Bayonet lock secure attachment. Rod lever release. 7:1 ratio leverage to provide easy control over pastes & gels. Full gun kit with (50) black syringe barrels, (50) rubber pistons, (50) end caps, (50) tip caps and (100) assorted tips.


Product Code Qty Price GBP Add
TS710SG-UV 1   each
  Adhesive dispensing syringe gun dispenser

Items are shipped in the UK by a courier on a tracked and insured service with products that are available from stock. Items on a longer lead time will be shipped as soon as they are made available.

Adhesive Dispensing Ltd provide a wide range of equipment options for dispensing almost all assembly fluids - from watery liquids, solvents, primers and activators through to thick pastes, sealants, silicones, gels and epoxies.

  Part ID: TS710SG-UV
  Materials: Nylon, Polypropylene, Polyethylene
  Colours: Red/ White
  Syringe Size: 10cc/ 10ml
  Gun Weight: 120 grams (without barrel)
  Gun Length: 265mm (including push rod)
  Gun Height: 135mm
  Warranty: 12 Months

The guns are robust and handle most liquids and pastes dispensed from them. However, it is important to press the small release button at the top of the gun before pulling the rod back when changing syringe barrels. O-rings can become worn or covered in glue so they are available to order from stock as replacements.

The gun is supplied with (1) spare rubber O-ring in the pack. For future replacement, select the 10cc size in EPR or Viton. Please contact us if replacement rods are required.

General Use: Guns are portable and can be used in a factory production or assembly department as well as for repair and re-work. Guns are commonly used in the field for repair or maintenance applications.

Common Applications:- Dots and beads of UV cure adhesives, solder paste, Dots and beads of solder flux, Grease to bearings, PVA glue to furniture joints, RTV to seal seams, Silicone dots to bond products, Gasket sealant repair, Shots of roach insecticides, General adhesive applications.
