Analog Timed Shot Dispenser
Bench top dispensing systems for the controlled application of liquids and pastes. Analog display with adjustable air regulator and an adjustable timer. Vacuum suck back to control drips. Make repeat shots or controlled beads of any liquid at the press of a footswitch. Worldwide voltage can be used anywhere.
TS9150 from Adhesive Dispensing Ltd

The TS9150 is a high quality timed liquid dispenser. It will apply watery liquids to thick pastes by simply adjusting the air pressure gauge - with repeat deposits using the adjustable timer or controlled beads when the timer is switched off. An adjustable vacuum suck-back prevents any watery liquids from dripping.

Its simplified design and operation makes it easy for anyone that has never used a pneumatic dispenser before. The unit allows repeat deposits or beads of RTVs, silicones, solder pastes, glues, UV cure, pastes, grease, primers, adhesives, epoxies and much more. Sits neatly on any work bench. Supplied with syringe barrels but options for using other barrel sizes from 3cc to 55cc.

Supplied complete with starter kit of 30cc barrels with wiper pistons, tip caps, barrel end caps, full tip kit, barrel adapter assembly hose, electric foot switch, power cord, airline hose, syringe stand, instruction guide and manuals. Covered by a two (2) year warranty and CE approved. This dispenser is available direct from stock.

This robust built benchtop dispenser is simple to use and operate and we offer full technical support for quick set up and for getting results.


Applications

Make dots of adhesives Dotting
Make beads of adhesives Beading
Potting of components Potting
Bonding of components Bonding
Sealing of components Sealing
Dispense lubricants and greases Lubricating
  Part ID: TS9150
  Type: Electro-pneumatic
Dispenser Initiate: Electric footswitch, or finger switch
  Pressure Display: Analog gauge 0-100 psi
  Timer Display: Rotary Knob
  Vacuum Display: None (manually adjustable knob)
  Dispense Timer: 0.01 to 31 seconds
  Dispense Modes: Timer or steady mode (continuous)
Output Pressure: To 100 PSI
  Input Pressure: 80-100 psi
  Size: 241 x 210 x 70mm
  Weight: 2.1kg
  Input Voltage: 110V AC - 220V AC
Warranty: 2 Years
  Cycle Rate: Up to 600 cycles/minute
  Timing Tolerances: +/- 0.1%
  Meets or Exceeds: CE, RoHS
  Mfg: ADL
  Commodity Code: 90269000
This compact cost effective dispenser sits on the work bench and requires an air input from any compressor or factory mains supply delivering 75 psi or above. All products are industrial grade and are covered by our no-quibble One Year warranty.

Dispensers are supplied with user guide to assist with the initial setting up process. Customers can contact us for full support and advice in using this timed barrel dispensing station.

What is supplied with the TS9150 Dispenser?

The package includes:

1 x TS9150 Dispensing System
1 x 100V-240V AC Power Adapter
1 x Airline Hose with Fittings Kit
1 x Electric Foot Switch
1 x Electric Finger Switch
1 x Syringe Barrel Bench Holder Stand

1 x 30cc Adapter Assembly with 3ft long Hose
3 x 30cc Clear Syringe Luer Lock Barrel
3 x 30cc/55cc Wiper Plastic Piston
3 x 30cc/55cc End Cap Seal
3 x Tip Cap Seal
20
x Assorted Needle Tips
1 x User Guide Setup Manual

Items are shipped in the UK by a courier on a tracked and insured service with products that are available from stock. Items on a longer lead time will be shipped as soon as they are made available.

General Use: Dispensers can be used in a factory production or assembly department to assemble products quickly and without material waste. They can be set to make repeat deposits of materials or controlled beads. These dispensers will handle watery liquids to thick pastes.

Common Applications:- Dots and beads of solder paste, Dots and beads of solder flux, Grease to bearings, PVA glue to furniture joints, RTV to seal seams, Silicone dots to bond products, Gasket sealant repair, Shots of roach insecticides, Modelling, General adhesive and glue applications. Any application to apply a controlled deposit of liquid or paste.

Adhesive Dispensing Ltd provide a wide range of equipment options for dispensing almost all assembly fluids - from watery liquids, solvents, primers and activators through to thick pastes, sealants, silicones, gels and epoxies.



More Info Part Code

Description / Quantity

Info Price GBP Add
TS9150 air powered timed adhesive dispenser TS9150
Timed Shot Dispenser
30cc / 30ml Barrels
Tariff Code: 90269000
Lead Time: 24 Hours
TS9150  Dispenser (1)
Clear Syringe Barrel (3)
White Wiper Piston (3)
Orange End Cap Seal (3)
Orange Tip Cap Seal (3)
Dispensing Tip (20)
TDS
Guide
Catalog
  each

More Info Part Code

Specs

Colour Lead Time

Qty

Price GBP Add
AD903-NW 903-NW
3cc Size Syringe Barrel & Piston Kit
Polypro Barrel Polyethylene Piston Clear Barrel White Piston 24 Hours 50   pack
AD905-NW 905-NW
5cc Size Syringe Barrel & Piston Kit
Polypro Barrel Polyethylene Piston Clear Barrel White Piston 24 Hours 50   pack
AD910-NW 910-NW
10cc Size Syringe Barrel & Piston Kit
Polypro Barrel Polyethylene Piston Clear Barrel White Piston 24 Hours 50   pack
AD930-NW 930-NW
30cc Size Syringe Barrel & Piston Kit
Polypro Barrel Polyethylene Piston Clear Barrel White Piston 24 Hours 50   pack
AD955-NW 955-NW
55cc Size Syringe Barrel & Piston Kit
Polypro Barrel Polyethylene Piston Clear Barrel White Piston 24 Hours 50   pack
703000CRPK 703000CRPK
Snap-On Barrel End Cap Seal
3cc Size
Polyethylene
Orange 24 Hours 50   pack
705000CRPK 705000CRPK
Snap-On Barrel End Cap Seal
5cc Size
Polyethylene
Orange 24 Hours 50   pack
710000CRPK 710000CRPK
Snap-On Barrel End Cap Seal
10cc Size
Polyethylene
Orange 24 Hours 50   pack
730000CRPK 730000CRPK
Snap-On Barrel End Cap Seal
30/55cc Size
Polyethylene
Orange 24 Hours 50   pack
70303RHB 70303RHB
3cc Syringe Barrel Adapter Assembly
Air link from barrel to air dispenser Yellow Head Clear Tube 24 Hours 1   each
70503RHB 70503RHB
5cc Syringe Barrel Adapter Assembly
Air link from barrel to air dispenser Yellow Head Clear Tube 24 Hours 1   each
71003RHB 71003RHB
10cc Syringe Barrel Adapter Assembly
Air link from barrel to air dispenser Yellow Head Clear Tube 24 Hours 1   each
73003RHB 73003RHB
30/55cc Syringe Barrel Adapter Assembly
Air link from barrel to air dispenser Yellow Head Clear Tube 24 Hours 1   each
DCK600 DCK600
Assorted Tip Kit in Hard Case
145 Assorted Luer Lock Tips Varied 24 Hours 1   each

  Small footprint takes up less space
  Integrated air pressure regulator
  Powerful vacuum suck back stops drips
  Timer for repeat deposits or beads
  Worldwide power voltage
  Footswitch and finger switch
  2 Year Warranty
Solder paste dots to PCBs
RTV beads to display cases
Grease deposits to bearings
Potting connectors & switches
Micro dots of adhesives
Ink and paint deposits
and many more...
