10oz Cartridge Retainer Air Cap and Air Hose
TS918-110CS 10oz 1/10 Gallon 310ml Retainer Cap

Our precision components provide safe and leak free fluid dispensing from cartridges. This aluminium retainer system is for pressurising all 10oz dispensing cartridges. A safe and leak free high pressure reservoir system.

A cartridge reservoir with cap and airline hose for direct feed to any metering valve or for dispensing adhesives and pastes directly from a timed dispenser.  10oz (310cc/ml) total volume.

Ideal for pastes, grease, adhesives, compounds, UV's and other fluids. Easy connect to any adjustable air regulator or air-powered dispenser. This system can also be used with 310ml or 1/10 Gallon size silicone and sealant cartridge tubes.

Includes a bayonet air cap with gasket, aluminium retainer body sleeve, airline hose with quick connect fitting, 10oz HDPE cartridge, cartridge wiper plunger, cartridge end cap, cartridge tip cap, threaded nozzle and a 1/4" NPT to male luer lock tip adapter fitting.

Adhesive Dispensing Ltd provide a wide range of equipment options for dispensing almost all assembly fluids - from watery liquids, solvents, primers and activators through to thick pastes, sealants, silicones, gels and epoxies.

Product Details

Copyright  2008 Adhesive Dispensing Ltd. All rights reserved.

Part ID: TS918-110CS
Materials: Aluminium/ Steel/ Nylon
Colour: Black/ Silver
Max Pressure: 100 PSI
Fluid Outlet: Silicone Cartridge to nozzle
Warranty: 1 Year
Lead Time: Ships within 24 Hours
Size Quantity Part Code Price Add
10oz 1 TS918-110CS GBP  each


310ml Cartridge Gun Accessories

More Info Part No.

Specs

Colour Lead Time

Pack

Price GBP Add
Cartridge HDPE Adhesive Dispensing Techcon Semco TS110CKIT
310ml Cartridge & Plunger Kit
1.85" OD/ 8.99" Long Natural/ White 24 Hours 10   pack
Cartridge HDPE Adhesive Dispensing Techcon Semco TS110CP
310ml Pre-Cartridge Plunger Kit
1.85" OD/ 8.99" Long Natural/ White 2 Weeks 250   pack
Cartridge HDPE Adhesive Dispensing Techcon Semco TS110CPW
310ml Pre-Cartridge Plunger Kit
1.85" OD/ 8.99" Long Natural/ Black 2 Weeks 250   pack
Cartridge HDPE Adhesive Dispensing Techcon Semco TS110C
310ml Cartridge Only
1.85" OD/ 8.99" Long Natural 24 Hours 10   pack
Cartridge HDPE Adhesive Dispensing Techcon Semco TS110C-LD
310ml Cartridge Only
1.85" OD/ 8.99" Long Natural 7 Days 250   pack
Cartridge Plunger Adhesive Dispensing Techcon TS2P
310ml Plunger Only
1.85" OD White 24 Hours 10   pack
Cartridge Plunger Adhesive Dispensing Techcon TS2P-BLACK
310ml Plunger Only
1.85" OD Black 24 Hours 10   pack
Cartridge Plunger Adhesive Dispensing Techcon TS2PW
310ml Plunger Only
1.85" OD Natural 7 Days 1000   pack
Cartridge End Cap Flange Seal Adhesive Dispensing TS4C
Flange Cap Seal
1.85" OD Red 24 Hours 10   pack
TS3P Cartridge Tip Cap Red 1/4" Adhesive Dispensing TS3P
Tip Cap Threaded Seal
21mm Dia. Red 24 Hours 10   pack
TS3P Cartridge Tip Cap Red 1/4" Adhesive Dispensing TS6P-RED
Mix Nozzle 1:1/2:1 Ratio
20mm Dia. Red 24 Hours 10   pack
Adhesive Dispensing Nozzle Cartridge Techcon Semco TS216
Standard Nozzle
2.5" L x 1/16" ID HDPE Natural 24 Hours 10   pack
Adhesive Dispensing Nozzle Cartridge Techcon Semco TS218
Standard Nozzle
2.5" L x 1/8" ID HDPE Natural 24 Hours 10   pack
Adhesive Dispensing Nozzle Cartridge Techcon Semco TS218-LD
Standard Nozzle
2.5" L x 1/8" ID LDPE Natural 24 Hours 50   pack
Adhesive Dispensing Nozzle Cartridge Techcon Semco TS416
Standard Nozzle
4.0" L x 1/16" ID HDPE Natural 24 Hours 10   pack
Adhesive Dispensing Nozzle Cartridge Techcon Semco TS416-LD
Standard Nozzle
4.0" L x 1/16" ID LDPE Natural 24 Hours 50   pack
Adhesive Dispensing Nozzle Cartridge Techcon Semco TS418
Standard Nozzle
4.0" L x 1/8" ID HDPE Natural 24 Hours 10   pack
Adhesive Dispensing Nozzle Cartridge Techcon Semco TS432
Standard Nozzle
4.0" L x 1/32" ID HDPE Natural 24 Hours 10   pack
Adhesive Dispensing Nozzle Cartridge Techcon Semco TS432-LD
Standard Nozzle
4.0" L x 1/32" ID LDPE Natural 24 Hours 50   pack
Adhesive Dispensing Nozzle Cartridge Techcon Semco TS490
Standard Nozzle
4.0" L x 3/32" ID HDPE Natural 24 Hours 10   pack
Nozzle Cartridge Ribbon Spreader Adhesive Dispensing TS1050
Ribbon Spread Nozzle
4.0" L x 0.50" W HDPE Natural 24 Hours 10   pack
Nozzle Cartridge Ribbon Spreader Adhesive Dispensing TS1075
Ribbon Spread Nozzle
4.0" L x 0.75" W HDPE Natural 24 Hours 10   pack
Nozzle Cartridge Ribbon Spreader Adhesive Dispensing TS1100
Ribbon Spread Nozzle
4.0" L x 1.0" W HDPE Natural 24 Hours 10   pack
Nozzle Cartridge Ribbon Spreader Adhesive Dispensing TS1175
Ribbon Spread Nozzle
4.0" L x 1.75" W HDPE Natural 24 Hours 10   pack
310ml Pneumatic Cartridge Dispensing Gun C-110CXO
Pneumatic Cartridge Gun
Max. 100 PSI Air Silver 24 Hours 1   each
310ml Pneumatic Cartridge Dispensing Gun 100A-10
Pneumatic Cartridge Gun
Max. 100 PSI Air Black 24 Hours 1   each
310ml Pneumatic Cartridge Dispensing Gun G-110
Pneumatic Cartridge Gun
Max. 100 PSI Air Black 72 Hours 1   each
310ml Pneumatic Cartridge Dispensing Gun 231551
Pneumatic Cartridge Gun
Max. 100 PSI Air Black 7 Days 1   each
310ml battery cordless dispensing gun Adhesive B600
Battery Cartridge Gun
Cordless Operated Silver 7 Days 1   each
230273
Manual Cartridge Gun
Hand Operated Silver 72 Hours 1   each
Dow Corning 744 RTV 310ml Adhesive Dispensing DC744W-310
White Silicone Sealant
Adhesive Sealant White 48 Hours 1   each


Cartridge Pages

  Robust construction
  Compatible with all 10oz sized cartridges
  Resistant to aggressive fluids and solvents
  Safe for use to 100 psi pressure
  Supplied in sealed packaging
