20oz Cartridge Retainer Air Cap and Air Hose
TS918-20CS 20oz Cartridge Retainer Cap Kit

Our precision components provide safe and leak free fluid dispensing from cartridges. This aluminium retainer system is for pressurising all 20oz dispensing cartridges. A safe and leak free high pressure reservoir system.

A cartridge reservoir with cap and airline hose for direct feed to any metering valve or for dispensing adhesives and pastes directly from a timed dispenser.  20oz (591cc/ml) total volume.

Ideal for pastes, grease, adhesives, compounds, UV's and other fluids. Easy connect to any adjustable air regulator or air-powered dispenser.

Includes a bayonet air cap with gasket, aluminium retainer body sleeve, airline hose with quick connect fitting, 20oz HDPE cartridge, cartridge wiper plunger, cartridge end cap, cartridge tip cap, threaded nozzle and a 1/4" NPT to male luer lock tip adapter fitting.

Adhesive Dispensing Ltd provide a wide range of equipment options for dispensing almost all assembly fluids - from watery liquids, solvents, primers and activators through to thick pastes, sealants, silicones, gels and epoxies.

Product Details

Copyright  2008 Adhesive Dispensing Ltd. All rights reserved.

Part ID: TS918-20CS
Materials: Aluminium/ Steel/ Nylon
Colour: Black/ Silver
Max Pressure: 100 PSI
Fluid Outlet: 1/4" NPT
Warranty: 1 Year
Lead Time: Usually Ships 5-7 Days
Size Quantity Part Code Price Add
20oz 1 TS918-20CS GBP  each


Cartridge Pages

  Robust construction
  Compatible with all 20oz sized cartridges
  Resistant to aggressive fluids and solvents
  Safe for use to 100 psi pressure
  Supplied in sealed packaging
