Cartridge Plungers

Cartridge Plungers Adhesive Dispensing Techcon

Offering the widest range of industrial dispensing cartridges for use with adhesives, gels, epoxies, silicones and lubricants. All plungers are industrial grade safe and are certified silicone-free. Plungers ensure liquids and pastes are dispensed from the cartridge without waste or mess.


Adhesive Dispensing Cartridge Sets

Plungers are for use with dispensing cartridges. The plunger is inserted into the cartridge once filled and moves down the inner walls under pressure to ensure all liquid material is dispensed without waste. Plungers can be used at pressures up to 100psi, for example when used with a pneumatic cartridge gun system. Select plunger size to suit the cartridge size.

All plungers are industry compliant silicone and chloride free, low friction polyethylene. Available in different colours and supplied in sealed packs.

** New TS1WP-RIB plungers have a single rear wiper blade and rib vents to improve insertion into the cartridge and a less restrictive wiper action under pressure. The close tolerance allows this plunger to move both ways and so reduces the affects of trapped air. In stock now.


Adhesive Dispensing Ltd provide a wide range of equipment options for dispensing almost all assembly fluids - from watery liquids, solvents, primers and activators through to thick pastes, sealants, silicones, gels and epoxies.


Plungers (All plungers fit 2.5, 6, 8 and 12oz size cartridges except TS2P and TS20P)


More Info Part No.

Size

Colour

Pack

Price Buy
TSW1P-RIB 2.5-12oz Natural 10   per pack
TS1P 2.5-12oz Blue 10

  per pack

TS1PB 2.5-12oz Black 10

  per pack

TS1WP 2.5-12oz Natural 10

  per pack

TS2P 10oz White 10

   per pack

TS20P 20/32oz White 10

  per pack

TS20PLD 20/32oz Natural 100

  per pack


Cartridges (Natural HDPE with 1/4" NPT Thread)


More Info Part No.

Size

Colour

Pack

Price Buy
TS25C 2.5oz Natural 10   per pack
TS25C-LD 2.5oz Natural 500   per pack
TS25C-GREEN 2.5oz Green 500   per kit
TS60C 6oz Natural 10   per pack
TS80C 8oz Natural 10   per pack
TS110C 10oz Natural 10   per pack
TS120C 12oz Natural 10   per pack
TS20C 20oz Natural 10   per pack
TS20C-BLACK 20oz Black 100   per pack
TS32C 32oz Natural 10   per pack

Cartridge Kits (Equal number of cartridges and plungers in sealed packs)

More Info Part No.

Size

Colour

Pack

Price Buy
TS25CKIT 2.5oz Natural 10   per kit
TS25CP-LD-500 2.5oz Natural 500   per kit
TS60CKIT 6oz Natural 10   per kit
TS80CKIT 8oz Natural 10   per kit
TS110CKIT 10oz Natural 10   per kit
TS120CKIT 12oz Natural 10   per kit
TS20CKIT 20oz Natural 10   per kit
TS20CP-100 20oz Natural 100   per kit
TS32CKIT 32oz Natural 10   per kit

Product Pages

  Silicone and chloride free plastics
  Resistant to aggressive fluids
  High density polyethylene HDPE
  Sizes 2.5 oz to 32 oz
  1/4" NPT standard threads on cartridges
  Supplied in sealed packs


  Adhesive dispensers   Metering valves   Syringe barrels   Dispensing tips   Cartridge reservoirs
  Dispensers & Valve Controllers   Fluid Dispensing
Valves
  Consumables
Syringes
  Dispensing Needle
Tips
  Cartridges & Dual Cartridges

Adhesive Dispensing Cartridges Techkits Semkits Nozzles

Air-Powered Dispensers * Industrial Dispensing Components * Precision Valve Systems * XYZ Bench Robots

Adhesives * Packaged Components * Techkits * RatioPacks * Hingepacks * Syringe Barrels * Cartridges * Nozzles


|  Privacy   |   Terms   |  Accounts  |

Prices are in UK pounds.  Vat is not charged on orders placed outside the EU and any EU orders are exempt from VAT only if a valid company VAT number is provided to us at time of order or before shipping.  Products are covered by a 12-month warranty against faults and malfunction.  All orders online are encrypted for safety and security.  Please read our privacy agreement for details.  We also process phone or fax payments by credit and debit card.  Please contact our accounts department if you would like to open a credit account with us.

Our new web shop is available to order these products in a number of different currencies. Please visit www.adhesivedispensing.co.uk for more details.

Disclaimer: While reasonable efforts have been made to ensure all information on this website is accurate, Adhesive Dispensing Ltd. do not assume responsibility for any errors or omissions. All specifications, illustrations, data and prices are subject to change without notice.

Copyright  2005 - 2017 Adhesive Dispensing Ltd. All rights reserved.





  Support

  Literature
  Cartridges Brochure
  Nozzles Brochure
  Dispense Guns Brochure
  Syringe Barrels Brochure
  Dispense Tips Brochure
  Dual Air Guns Sheet
  Full Catalogue

  Information
  Important Safety Information
  Viscosities Chart

  Contact Us
  Equipment Recommendations
  Request a Quote
  Technical Support
  Applicator Assist

  Shipment of these products


Products are shipped in the UK by courier on a next day tracked & insured service. Europe deliveries, items are shipped via DPD or DHL. For all international shipments, items are sent DHL or via FedEx.



  More Information


Plungers are moulded in low density plastics for a close interference fit inside the cartridge inner walls. For viscous pastes and gels, the plunger will wipe the inside as it moves down to cartridge to prevent waste and mess.



  Industrial Grade Safe


Plungers are safe for use up to 100 psi air pressure. These components are not for medical applications but are precision manufactured for  industrial use.



  Silicone-Free Components


Plungers are certified silicone-free components to ensure they do not contaminate any fluids or adhesives that are dispensed from them.
