Home > Components > Barrels > 460T-1




60cc Size Luer Lock Clear Syringe Barrel with Nozzle Tip

Industrial barrels are for use with any of our air-powered dispensers or as a manual syringe assembly. If using with an air-powered dispenser, an adapter assembly is required and use the plastic pistons. If using manually, select a rubber piston and a plastic push rod.


410T-1 10cc syringe barrel Techcon Adhesive Dispensing


Industrial grade 10cc/ 10ml size syringe barrels. Clear (natural) for use with all adhesives iand gels. High density polypropylene safe for use up to 100 psi.

Precision flanges for safe attachment to the receiver assembly.  This version includes a moulded tapered nozzle tip. Use with standard wiper pistons.

Syringe barrels are industry compliant silicone free, low friction polypropylene. Supplied in a sealed pack.

Adhesive Dispensing Ltd provide a wide range of equipment options for dispensing almost all assembly fluids - from watery liquids, solvents, primers and activators through to thick pastes, sealants, silicones, gels and epoxies.


460T-1 Barrel

Excludes Carriage.
Lead Time:
Usually Ships within 72 Hours

Summary: Luer lock dispensing syringe barrels for air powered dispensers and syringe guns.

Item Qty Price GBP Add
460T-1 50   pack

Specifications:

Materials: High Density Polypro
Colour: Natural Translucent
Length: 154.94mm
Outer Diameter: 29.72mm
Inner Diameter: 26.67mm
Connection Type: Luer Lock
Maximum Pressure: 100 PSI (6.89 Bar)

Flow Pattern: Straight
Description: Air Syringe Barrel
Features: Silicone-Free, Industrial Grade



Delivery: Products shipped by courier on a tracked and insured service for stock items.

Products on a longer lead time or built to order will be sent as soon as available. Customers are informed of ship dates and updates.

Typical Applications:- These barrels are used on pneumatic dispensing machines and manual plunger rods.

For most liquids, pastes, epoxies, gels, solvents, adhesives, fluxes, lubricants, paints, inks, solder creams, braze pastes and many more assembly fluids.

Adhesive dispensing syringe barrels


Barrel Pages


  Silicone and chloride free plastic
  Industrial grade safe to 100 psi
  Resistant to aggressive fluids & solvents
  High precision moulded part
  Use with air dispensers and manual rods
  Compatible with industry standard equipment

Barrel Accessories
More Info Part No.

Specs

Colours Lead Time

Pack

Price GBP Add
460L-9 60cc White Piston 460L-9
60cc White Air Power Piston
Polyethylene Low Density White 24 Hours 50   pack
460L-2 60cc Black Rubber Syringe Piston Stopper Techcon 460L-2
60cc Manual Rubber Piston
Rubber Medium Density Black 24 Hours 50   pack
460L-2-LUB 60cc Black Rubber Syringe Piston Stopper Techcon 460L-2-LUB
60cc Manual Rubber Piston
Rubber Medium Density Black 24 Hours 50   pack
460L-4 60cc Manual Syringe Plunger Rod Techcon 460L-4
60cc Manual Plunger Rod
Polypro High Density Grey 24 Hours 50   pack
460LL-1 60cc Syringe Barrel Techcon 460LL-1
60cc Luer Lock Syringe Only
Polypro High Density Clear 24 Hours 50   pack
MS460LL-1 60cc Manual Syringe Assembly Techcon MS460LL-1
60cc Full Syringe Assembly
Polypro High Density Clear 24 Hours 50   pack
900-1150-3 60cc Adapter Receiver Assembly Techcon 900-1150-3
60cc Adapter Assembly 3 ft.
Polypro to Polyurethane Blue 24 Hours 1   each
900-1150-6 60cc Adapter Receiver Assembly Techcon 900-1150-6
60cc Adapter Assembly 6 ft.
Polypro to Polyurethane Blue 24 Hours 1   each
900-1150-R 60cc Adapter Receiver Assembly Techcon 900-1150-R
60cc Adapter Head Only
Polypro to Polyurethane Blue 24 Hours 1   each
7015LLPK Tip Cap Seal Orange Luer Lock AD900-ORTC 7015LLPK
Universal Luer Tip Cap Seal
Polypro High Density Orange 24 Hours 50   pack
Copyright  2008 Adhesive Dispensing Ltd. All rights reserved. 7015LLBPK
Universal Luer Tip Cap Seal
Polypro High Density Black 24 Hours 50   pack
Orange tri-seal tip cap 800-ORTC
Round Luer Tip Cap Seal
Polypro High Density Orange 24 Hours 50   pack
Black threaded tip cap 800-BLTC
Round Luer Tip Cap Seal
Polypro High Density Black 24 Hours 50   pack
Adhesive dispensers TS250
Digital Timed Air Dispenser
0.02 to 60 sec timer, 0-100 PSI Black 24 Hours 1   each
Adhesive dispensers TS255
Digital Timed Air Dispenser
0.02 to 60 sec timer, 0-15 PSI Black 24 Hours 1   each
