White Flexible Feed Tube 3/16 Inch OD 1/8 Inch ID

Our fluid lines offer safe and leak free connections between syringes, cartridges, dispense valves and pressure pots. Use this industrial grade feed tubing with most fluids, liquids, solvents, adhesives, inks and gels.

TSD1099-11 Feed Tubing 1/4" Adhesive Dispensing


A flexible white polyethylene 3/16 Inch OD feed tubing 1/8 Inch ID. Suitable for most fluids and solvents providing a safe feed from pressure pot or cartridge reservoir to any dispense valve.

Priced per 10 ft. lengths. Produced with compounds listed by NSF Standards 51 and 61, and in compliance with FDA 21 CFR 175.105. Use with 1/8" ID barb fittings or 1/4" compression fittings..

Specifications & Description

Tubing Formulation: Polyethyelene
Tubing OD: (in) 3/16
Tubing OD: (mm) 4.7625
Tubing ID: (in) 1/8
Tubing ID: (mm) 3.0
Wall Thickness: (in) 1/16
Wall Thickness: (mm) 1.58
Color: White
Clarity (translucent): 30%
Max Pressure (PSI): 450
Max Pressure (bar): 31
Min Temperature (Deg F) -83
Max Temperature (Deg F) 170
Min Temperature (Deg C) -63
Max Temperature (Deg C) 76
Length (ft) 10
Sterilization Method (EtO) Yes
Description FX Flexible Polyethylene, Non-DEHP


More Info Part Code

Specs

Colour Lead Time

Pack

Price GBP Add
Feed Tubing in clear (natural), White and black (opaque) colours. Natural for most materials and black for UV cure adhesives. Polyethylene tubes with open ends for attachment to fittings. Maximum pressure 100 psi. Use with dispensing valves, pressure pots, cartridges and syringe barrels. All prices are per length of (10 ft.).
Fluid line feed tubing TSD1099-12 Adhesive Dispensing TSD1099-12
1/8" (3.00mm (ID)
3/16" (4.76mm OD)
Polyethylene Flexible Tube  White 24 Hours 10 ft.   pack

Fluid line feed tubing TSD1099-24 Adhesive Dispensing TSD1099-24
1/8" (3.00mm (ID)
1/4" (6.40mm OD)
Polyethylene Flexible Tube  Natural 24 Hours 10 ft.   pack
Fluid line feed tubing TSD1099-11 Adhesive Dispensing TSD1099-11
1/8" (3.00mm (ID)
1/4" (6.40mm OD)
Polyethylene Flexible Tube  White 24 Hours 10 ft.   pack
Fluid line feed tubing TSD1099-23 Adhesive Dispensing TSD1099-23
1/4" (6.40mm (ID)
3/8" (9.96mm OD)
Polyethylene Flexible Tube  Natural 24 Hours 10 ft.   pack
Fluid line feed tubing TSD1099-45 Adhesive Dispensing TSD1099-45
4mm ID Metric
6mm OD Metric
Polyethylene Flexible Tube  Natural 24 Hours 10 ft.   pack
Fluid line feed tubing Techcon TSD1099-25 TSD1099-25
1/8" (3.00mm (ID)
1/4" (6.40mm OD)
Polyethylene Flexible Tube Black 24 Hours 10 ft.   pack
Fluid line feed tubing Techcon TSD1099-22 TSD1099-22
1/4" (6.40mm (ID)
3/8" (9.96mm OD)
Polyethylene Flexible Tube Black 24 Hours 10 ft.   pack
Fluid line feed tubing Techcon TSD1099-46 TSD1099-46
4mm ID Metric
6mm OD Metric
Polyethylene Flexible Tube Black 24 Hours 10 ft.   pack

More Info Part Code

Specs

Colour Lead Time

Pack

Price GBP Add
Fluid Line tubes in clear (natural) and black (opaque) colours. Natural for most materials and black for UV cure adhesives. Polyethylene tubes with luer lock attachment. Maximum pressure 100 psi. Use with dispensing valves, pressure pots, cartridges and syringe barrels. Length options. All prices are for sealed packs of (10).
Fluid line feed tubing adhesive dispensing TSD126-118PK TSD126-118PK
0.100" (2.54mm (ID)
0.150" (3.81mm OD)
18" (457.0mm) Long
Male Luer Lock to Open End Natural 24 Hours 10   pack
Fluid line feed tubing adhesive dispensing TSD126-124PK TSD126-124PK
0.100" (2.54mm (ID)
0.150" (3.81mm OD)
24" (610.0mm) Long
Male Luer Lock to Open End Natural 24 Hours 10   pack
Fluid line feed tubing adhesive dispensing TSD126-136PK TSD126-136PK
0.100" (2.54mm (ID)
0.150" (3.81mm OD)
36" (914.0mm) Long
Male Luer Lock to Open End Natural 24 Hours 10   pack
Fluid line feed tubing adhesive dispensing TSD126-218PK TSD126-218PK
0.100" (2.54mm (ID)
0.150" (3.81mm OD)
18" (457.0mm) Long
Female Luer Lock to Open End Natural 24 Hours 10   pack
Fluid line feed tubing adhesive dispensing TSD126-224PK TSD126-224PK
0.100" (2.54mm (ID)
0.150" (3.81mm OD)
24" (610.0mm) Long
Female Luer Lock to Open End Natural 24 Hours 10   pack
Fluid line feed tubing adhesive dispensing TSD226-136PK TSD126-236PK
0.100" (2.54mm (ID)
0.150" (3.81mm OD)
36" (914.0mm) Long
Female Luer Lock to Open End Natural 24 Hours 10   pack
Fluid line feed tubing adhesive dispensing TSD126-318PK TSD126-318PK
0.100" (2.54mm (ID)
0.150" (3.81mm OD)
18" (457.0mm) Long
Male Luer Lock to Female Luer Lock Natural 24 Hours 10   pack
Fluid line feed tubing adhesive dispensing TSD126-324PK TSD126-324PK
0.100" (2.54mm (ID)
0.150" (3.81mm OD)
24" (610.0mm) Long
Male Luer Lock to Female Luer Lock Natural 24 Hours 10   pack
Fluid line feed tubing adhesive dispensing TSD126-336PK TSD126-336PK
0.100" (2.54mm (ID)
0.150" (3.81mm OD)
36" (914.0mm) Long
Male Luer Lock to Female Luer Lock Natural 24 Hours 10   pack
Fluid line feed tubing adhesive dispensing TSD126-418PK TSD126-418PK
0.100" (2.54mm (ID)
0.150" (3.81mm OD)
18" (457.0mm) Long
Female Luer to Female Luer Lock Natural 24 Hours 10   pack
Fluid line feed tubing adhesive dispensing TSD126-424PK TSD126-424PK
0.100" (2.54mm (ID)
0.150" (3.81mm OD)
24" (610.0mm) Long
Female Luer to Female Luer Lock Natural 24 Hours 10   pack
Fluid line feed tubing adhesive dispensing TSD126-436PK TSD126-436PK
0.100" (2.54mm (ID)
0.150" (3.81mm OD)
36" (914.0mm) Long
Female Luer to Female Luer Lock Natural 24 Hours 10   pack
Fluid line feed tubing adhesive dispensing TSD126-524PK TSD126-524PK
0.100" (2.54mm (ID)
0.150" (3.81mm OD)
24" (610.0mm) Long
Male Luer Lock to Male Luer Lock Natural 24 Hours 10   pack
Black Fluid Line Luer Lock TSD126-318BPK Techcon TSD126-318BPK
0.100" (2.54mm (ID)
0.150" (3.81mm OD)
18" (457.0mm) Long
Male Luer Lock to Female Luer Lock Black 24 Hours 10   pack
Black Fluid Line Luer Lock TSD126-324BPK Techcon TSD126-324BPK
0.100" (2.54mm (ID)
0.150" (3.81mm OD)
24" (610.0mm) Long
Male Luer Lock to Female Luer Lock Black 24 Hours 10   pack
Black Fluid Line Luer Lock TSD126-336BPK Techcon TSD126-336BPK
0.100" (2.54mm (ID)
0.150" (3.81mm OD)
36" (914.0mm) Long
Male Luer Lock to Female Luer Lock Black 24 Hours 10   pack
Black Fluid Line Luer Lock TSD126-360BPK Techcon TSD126-360BPK
0.100" (2.54mm (ID)
0.150" (3.81mm OD)
60" (1525.0mm) Long
Male Luer Lock to Female Luer Lock Black 24 Hours 10   pack

Items are shipped in the UK by a courier on a tracked and insured service with products that are available from stock. Items on a longer lead time will be shipped as soon as they are made available.
