2 Litre Pressure Pot with Adjustable Air Regulator

Our pressure tanks keep a steady fluid pressure, eliminate fluid contamination and evaporation, and eliminate fumes. Models are available to suit many liquids, adhesives and solvents. This stainless steel version has adjustable air pressure and is supplied complete with fluid lines and fittings. Use the adjustable regulator on the lid to provide a constant flow of liquid.

2 Liter Pressure Pot Adhesive Dispensing AD8202


The AD8202 Pressure Pot (pressure up to 100 psi) is designed to accommodate all solvents and adhesives, as well as cyanoacrylates and UV's. It will also accommodate clear and black fittings and tubing in 1/4, 3/8, and 4mm, with stainless steel compression fittings for a continuous fluid path from the reservoir inside the pot to the point of use.

Airtight seals ensure no leakage or air entrapment problems. 100 psi operating pressure easily handles fluid with viscosity up to 30,000 CPS. Disposable polyethylene dip tube can be quickly changed. The pressure gauge and pressure regulator are located on top for easy reading and access. Includes fluid line connector kit.

When dispensing adhesives, a container or bottle is best placed inside the tank chamber. Do not pour curable adhesives directly into the pot. Non curing liquids are OK. Main tank body and lid is stainless steel.

All products are CE approved, certified industrial grade and are covered by our no-quibble One Year warranty.

Adhesive Dispensing Ltd provide a wide range of equipment options for dispensing almost all assembly fluids - from watery liquids, solvents, primers and activators through to thick pastes, sealants, silicones, gels and epoxies.


2 Liter Pressure Pot Tank

GBP   each ex. Vat.
Excludes carriage.
Product Code: AD8202
Lead Time: Ships Around 1-2 Weeks


Summary: Standard tank unit with lid, adjustable air pressure gauge, stainless steel tube fitting, 6mm OD flexible tube, user guide. CE approved.

Product Code Qty Price GBP Add
AD8202 1   each

1 Liter Pressure Pot Tank

GBP   each ex. Vat.
Excludes carriage.
Product Code: TS1251
Lead Time:
Ships Around 1-2 Weeks

Summary: Standard tank unit with lid, adjustable air pressure gauge, stainless steel tube fitting, 1/4" OD flexible tube, user guide. CE approved.

Product Code Qty Price GBP Add
TS1251 1   each

  Part ID: AD8202
  Materials: Stainless Steel Type 304
  Product Colour: Silver Body and Lid
  Outer Dimensions: 195.1mm W x 253.4mm H
  Inner Tank Size: 152.1mm W x 350.3mm H
  Weight: 4.0 kg
  Maximum Pressure Up to 100 PSI (7 Bar)
  Meets: CE Approval
  Warranty: 1 Year

Items are shipped by a courier on a tracked and insured service for all items that are available from stock. Items on a lead time will be shipped as soon as they are available.

Tanks will handle low to medium viscosity liquids up to 30,000 CPS. Includes thin solvents, liquid, fluxes, flowable silicones, Cyanoacrylate, UV cure, inks, paints, lubricants, threadlockers & more.
