Static Mixer Nozzle 8.7mm ID x 24 Mix Elements |
|
High density moulded
static mixer nozzles with screw thread attachment to
dual cartridges.
Stepped end design for direct dispensing or attachment of reducer
fitting when using small luer lock needle tips. Silicone free and
industrial grade. |
|
|
|
Screw inlet, helical static mixer nozzle for 200ml, 400ml and 600ml
C-System
dual component cartridges. Straight end outlet providing controlled
flow or use with a dispensing tip.
These mixer nozzles
are suitable for 1:1 and 2:1 ratio two-component materials and C-System
bell mouth type cartridges. These nozzles thread onto the cartridge
without the need for a locking collar.
They have green elements and
are constructed of high grade polypropylene. All items are
industrial grade safe and silicone free.
Static mixer nozzles are
available in many different styles and with stepped,open or luer
ends.
All products shipped are in sealed boxes or packs
that
include printed label with batch codes.
Adhesive Dispensing Ltd provide a wide range
of equipment options for dispensing almost all assembly fluids -
from watery liquids, solvents, primers and activators through to
thick pastes, sealants, silicones, gels and epoxies. |
|
|
|
|
|
|
Specifications
Materials: Polypropylene Colour:
Natural Body/ Green Elements Mix Ratios: Use with 1:1/ 2:1 Only
Length: 161.0mm Inner Diameter: 8.7mm Outer Diameter: 10.7 mm
Number of Elements: 24 Retained Material Volume:
8.61
ml Connection Type: Threaded Screw-On
Maximum Pressure: 100 PSI (6.89 Bar)
Flow Pattern: Straight
Description: Static Mixer Nozzle
Features: Silicone-Free, Industrial Grade Commodity Code:
39235090
|
|
|
|
|
Delivery: Products
shipped by courier on a tracked and
insured service for stock items.
Products on a
longer
lead time or built to order will be sent as soon as available. Customers are informed of
ship dates.
Typical Applications:- Deposits of
epoxy resins, two-part silicones, PU Polyurethanes and many other 2-component
and mixed materials. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
