High quality stainless
steel burr-free tube to moulded colour coded polypropylene hub with
double-helix luer lock. Use this tip for dispensing adhesives,
solvents, glues, primers, activators and others. A precision cut
tube stainless
shaft length of 2 Inch (50.8mm).
TE needle
series consist of a stainless-steel shaft with a double helix
polypropylene hub. This premier line of dispensing needles is
burr-free, and electro-polished shaft for unobstructed and
consistent material flow.
Suitable for dispensing most
fluids, adhesives and solvents. Certified silicone-free,
chloride-free and industrial grade safe for use to 100 psi.
Tips are colour coded for gauge size. The tip features a tapered
internal design where the shaft meets the hub to improve fluid flow
and reduce restriction. This allows for a lower pressure to be
used for dispensing gels and pastes.
All products shipped are in sealed boxes or packs
that
include label with batch codes.
Adhesive Dispensing Ltd provide a wide range
of equipment options for dispensing almost all assembly fluids -
from watery liquids, solvents, primers and activators through to
thick pastes, sealants, silicones, gels and epoxies.
TE720200PK Tip 2 Inch Long
Excludes
Carriage. Lead Time: Usually Ships
72 Hours
Summary: Dispensing nozzle
tips blunt end stainless steel tube to poypro hub.
Item
Qty
Price
GBP
Add
TE720200PK
50
pack
Specifications
Materials: Polypro Hub, Stainless Steel
Tube Hub Colour: Pink
Tip
Tube
Length: 50.8mm (2 Inch) Tip Tube ID: 0.61mm (0.024 Inch) Tip Tube
OD: 0.91mm (0.036
Inch)
Connection Type: Double Helix Luer Lock Maximum Pressure: 100 PSI (6.89 Bar) Flow Pattern: Straight Description: General Purpose Tip
Features: Silicone-Free, Industrial Grade
Pack Sizes: 50
Delivery: Products
shipped by courier on a tracked and
insured service for stock items. Products on a
longer
lead time or built to order will be sent as soon as available. Customers are informed of
ship dates.
Typical Applications:- Deposits
of solder paste or solder flux, grease to bearings, potting
components with epoxies, RTV to edge seams, silicone shots to bond
products, gasket sealant repair, aircraft maintenance work, braze
pastes, solvents, threadlockers, general
adhesive applications.
