Needle Tip 1.5" Luer teflon dispensing needles TF18-15

Adhesive Dispensing

You currently have items in your basket. (Total=)

Home > Components > Tips > Teflon Tips > TF18-15

Flexible Teflon Tube Dispense Tip 18 Gauge

Dispensing tip with long flexible translucent clear tube and threaded luer lock colour coded hub for secure attachment to syringe barrels or dispense valves. Ideal for use with Cyanoacrylates and other low viscosity liquids as adhesives will not stick to the tube or clog. The soft clear shaft allows fluid flow to be seen.

TF18-15 Teflon PTFE Adhesive Dispensing Tip 18 GA

A semi-flexible 18 gauge olive tip with 1.5 Inch long Teflon tube. Threaded polypropylene hub.

Ideal for use with cyanoacrylates, solvents and many other low to medium viscosity fluids. Teflon tube will not clog rapidly during use.

Attaches to syringe barrels, valves or dispensing bottles.

Clear translucent tube attached below the colour coded hub allows fluid flow to be viewed during dispensing. 0.042 Inch ID. Shaft length of 1.5 Inch (38.1mm).

Supplied in sealed boxes of 50. Bulk packs of 1000 are available on request.

Adhesive Dispensing Ltd provide a wide range of equipment options for dispensing almost all assembly fluids - from watery liquids, solvents, primers and activators through to thick pastes, sealants, silicones, gels and epoxies.

TF18-15 Teflon Dispense Tip

Excludes Carriage.
Lead Time: Usually Ships 72 Hours

Summary: Dispensing tips for applying deposits of Cyanoacrylate adhesives and other liquids.

Item	Qty	Price GBP	Add
TF18-15	50	box

Specifications

Materials: Teflon, Polypropylene
Colour: Pink Hub, Clear Tube
Tip ID: 1.067mm (0.042 Inch)
Tip OD: 1.372mm (0.054 Inch)
Tip Tube Length: 38.1mm (1.5 Inch)
Connection Type: Double Helix Luer Lock
Maximum Pressure: 100 PSI (6.89 Bar)
Flow Pattern: Straight
Description: Tip for CA Adhesives
Features: Silicone-Free, Industrial Grade
Pack Size: 50

Delivery: Products shipped by courier on a tracked and insured service for stock items.

Products on a longer lead time or built to order will be sent as soon as available. Customers are informed of ship dates and updates.

Typical Applications:- Use these tips for deposits of Cyanoacrylate adhesives, inks, oils, primers, liquids, acivators and many other assembly fluids.

For viscous pastes and epoxies, use our smooth flow tapered tips.

Part	Gauge	Length	Colour	Inner Diameter	Outer Diameter	Lead Time	Price GBP	Add
TF14-1/2	14	12.7mm	Olive	1.676mm	2.083mm	24 Hours	pack 50
TF14-1	14	25.4mm	Olive	1.676mm	2.083mm	48 Hours	pack 50
TF14-15	14	38.1mm	Olive	1.676mm	2.083mm	72 Hours	pack 50
TF14-2	14	50.8mm	Olive	1.676mm	2.083mm	72 Hours	pack 50
TF14-3	14	76.0mm	Olive	1.676mm	2.083mm	72 Hours	pack 50
TF16-1/2	16	12.7mm	Purple	1.346mm	1.650mm	24 Hours	pack 50
TF16-1	16	25.4mm	Purple	1.346mm	1.650mm	48 Hours	pack 50
TF16-15	16	38.1mm	Purple	1.346mm	1.650mm	48 Hours	pack 50
TF16-2	16	50.8mm	Purple	1.346mm	1.650mm	24 Hours	pack 50
TF16-3	16	76.0mm	Purple	1.346mm	1.650mm	48 Hours	pack 50
TF18-1/2	18	12.7mm	Pink	1.067mm	1.372mm	24 Hours	pack 50
TF18-1	18	25.4mm	Pink	1.067mm	1.372mm	48 Hours	pack 50
TF18-15	18	38.1mm	Pink	1.067mm	1.372mm	72 Hours	pack 50
TF18-2	18	50.8mm	Pink	1.067mm	1.372mm	72 Hours	pack 50
TF18-3	18	76.0mm	Pink	1.067mm	1.372mm	72 Hours	pack 50
TF20-1/2	20	12.7mm	Yellow	0.864mm	1.168mm	24 Hours	pack 50
TF20-1	20	25.4mm	Yellow	0.864mm	1.168mm	24 Hours	pack 50
TF20-15	20	38.1mm	Yellow	0.864mm	1.168mm	24 Hours	pack 50
TF20-2	20	50.8mm	Yellow	0.864mm	1.168mm	24 Hours	pack 50
TF20-3	20	76.0mm	Yellow	0.864mm	1.168mm	24 Hours	pack 50
TF22-1/2	22	12.7mm	Black	0.711mm	1.016mm	24 Hours	pack 50
TF22-1	22	25.4mm	Black	0.711mm	1.016mm	24 Hours	pack 50
TF22-15	22	38.1mm	Black	0.711mm	1.016mm	24 Hours	pack 50
TF22-2	22	50.8mm	Black	0.711mm	1.016mm	24 Hours	pack 50
TF23-1/2	23	12.7mm	Blue	0.660mm	0.965mm	24 Hours	pack 50
TF24-1/2	24	12.7mm	Red	0.559mm	0.864mm	24 Hours	pack 50
TF24-1	24	25.4mm	Red	0.559mm	0.864mm	24 Hours	pack 50
TF30-1/2	30	12.7mm	Lavender	0.305mm	0.610mm	24 Hours	pack 50
TF30-1	30	25.4mm	Lavender	0.305mm	0.610mm	72 Hours	pack 50
TF30-1.5	30	38.1mm	Lavender	0.305mm	0.610mm	72 Hours	pack 50
TF30-2	30	50.8mm	Lavender	0.305mm	0.610mm	72 Hours	pack 50
