Techkit Cartridge Gallon Open Spoke Mix Head |
|
Offering the widest range of
dispensing components used in dispensing two component
materials. This mixer head is used with 2.5oz, 6oz and 8oz
size cartridges, plungers, rods and ram rods. It is for use
with the injection Techkit assembly. |
|
 |
|
|
For
compounds with a volumetric ratio less than 10 parts per 100. The
catalyst is contained inside the hollow valved mixing rod while the
base material is inside the body of the cartridge. A ram rod is
provided to push the catalyst from the hollow mixing rod into the
main cartridge. Once mixed, the rod is simply removed and a
dispensing nozzle is attached. It can then be placed into an
applicator gun and dispensed. |
|
The Techkit is a compact and
simple method of packaging two or three component resin
systems into a 2 1/2, 6, 8, 20 ounce or 1/10 gallon
cartridge. The kit mechanically separates the base and
hardener until they are ready to be used.
An
internal mixing head provides a thorough blend for all types
of compounds. When the job has been completed, the entire
package is disposed of: no clean up or physical contact with
the resin. Reliability is increased with accurate compound
ratios, complete mixing and proper application techniques.
Adhesive Dispensing Ltd provide a wide range of
equipment options for dispensing almost all assembly fluids
- from watery liquids, solvents, primers and activators
through to thick pastes, sealants, silicones, gels and
epoxies. |
|
|
|
|
 |
|
|
|
|
|
Order online securely |
|
Part Code |
Pack Size |
Description |
Lead Time |
Price GBP |
Add |
|
600-200PK |
50 |
Open Spoke Mixing Head |
in stock |
pk/50 |
 |
|
600-200 |
500 |
Open Spoke Mixing Head |
in stock |
pk/500 |
|
|
 |
Operators can mix the kit
manually, semi-automatically or automatically using Techkit
mixing equipment. The dasher rod is then quickly removed
and a nozzle attached, then placed in a manual or pneumatic
dispensing gun. After application, the nozzle and kit are
disposable, reducing labour and production costs.
The Techkit cartridge system mixes a wide range of materials
with varying viscosities without mess, waste or
contamination. No special storage is required. Each kit is
packaged with a printed safety label, shelf life, special
instructions, batch code and date of fill. All kits feature
a 1/4" NPT threaded outlet to accept a wide range of
dispensing nozzles or smaller dispense tips when used with a
needle adapter. |
|
|
|
|
 |
|
|
Delivery: Products
shipped by courier on a tracked and
insured service for stock items. Products on a
longer
lead time or built to order will be sent as soon as available. Customers are informed of
ship dates.
Typical Applications:- Deposits of
low viscosity liquids, paints, inks, primers, solvents and other assembly fluids. |
|
|
|
Adhesive Dispensing Ltd provide a wide
range of equipment options for dispensing almost all assembly fluids - from
watery liquids, solvents, primers and activators through to thick pastes,
sealants, silicones, gels and epoxies. |
|
|
|
|
|
|
|
|
|
|
